Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
86
C3339 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3340 1-118-310-11 CERAMIC CHIP 0.022uF 10% 100V
C3341 1-118-310-11 CERAMIC CHIP 0.022uF 10% 100V
C3356 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C3357 1-118-066-11 CERAMIC CHIP 0.1uF 10% 100V
C3363 1-118-119-91 CERAMIC CHIP 0.47uF 10% 100V
C3364 1-118-119-91 CERAMIC CHIP 0.47uF 10% 100V
C3371 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3372 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3381 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3382 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3401 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3402 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3403 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3404 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3405 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3406 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3407 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3408 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3451 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3452 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3453 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3454 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3455 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3456 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3457 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3458 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3459 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3460 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3461 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3462 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3463 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3464 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3465 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3466 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3502 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3503 1-117-681-11 ELECT CHIP 100uF 20% 16V
C3504 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3505 1-128-992-21 ELECT CHIP 47uF 20% 25V
C3552 1-126-208-21 ELECT CHIP 47uF 20% 4V
C3554 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3555 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3557 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C3574 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
< CONNECTOR >
* CN3501 1-695-320-21 PIN, CONNECTOR (1.5MM) (SMD) 2P
< DIODE >
D3101 6-503-733-01 DI 1SMB51AT3G
D3102 6-503-733-01 DI 1SMB51AT3G
D3103 6-503-733-01 DI 1SMB51AT3G
D3104 6-503-733-01 DI 1SMB51AT3G
D3151 8-719-056-48 DI 1SS388
D3301 6-503-733-01 DI 1SMB51AT3G
D3302 6-503-733-01 DI 1SMB51AT3G
D3303 6-503-733-01 DI 1SMB51AT3G
D3304 6-503-733-01 DI 1SMB51AT3G
D3351 8-719-056-48 DI 1SS388
D3501 6-502-961-01 DI DA2J10100L
D3503 8-719-056-48 DI 1SS388
D3504 8-719-056-48 DI 1SS388
< IC >
IC3001 6-718-103-01 IC TAS5538DGGR
0
IC3102 6-718-787-01 IC STA516BE
0 IC3302 6-718-787-01 IC STA516BE
0 IC3501 6-716-739-01 IC BD00GC0WEFJ-SE2
< COIL >
L3051 1-469-525-91 INDUCTOR 10uH
L3101 1-481-939-11 INDUCTOR 20uH
L3103 1-481-939-11 INDUCTOR 20uH
L3301 1-481-939-11 INDUCTOR 20uH
L3303 1-481-939-11 INDUCTOR 20uH
L3501 1-469-526-91 INDUCTOR 22uH
< TRANSISTOR >
Q3101 6-552-772-01 TR RT3AMMAM1-T111-1F
Q3202 6-552-772-01 TR RT3AMMAM1-T111-1F
Q3302 6-552-772-01 TR RT3AMMAM1-T111-1F
Q3501 6-552-408-01 TR DSC500100L
Q3512 6-552-433-01 TR DRC5115E0L
Q3552 6-551-272-01 TRANSISTOR RT3CLLM
Q3553 6-552-408-01 TR DSC500100L
Q3554 6-552-760-01 TR SSM3J325F, LSOYF
Q3555 6-552-772-01 TR RT3AMMAM1-T111-1F
< RESISTOR >
R3021 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R3022 1-218-967-11 METAL CHIP 15K 5% 1/16W
R3023 1-218-949-11 METAL CHIP 470 5% 1/16W
R3024 1-218-949-11 METAL CHIP 470 5% 1/16W
R3025 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3026 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3028 1-216-864-11 SHORT CHIP 0
R3029 1-216-864-11 SHORT CHIP 0
R3033 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3040 1-216-295-91 SHORT CHIP 0
R3041 1-216-805-11 METAL CHIP 47 5% 1/10W
R3042 1-216-864-11 SHORT CHIP 0
R3043 1-216-864-11 SHORT CHIP 0
R3044 1-216-295-91 SHORT CHIP 0
R3051 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3059 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3060 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3061 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3062 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3072 1-216-805-11 METAL CHIP 47 5% 1/10W
R3073 1-216-805-11 METAL CHIP 47 5% 1/10W
R3074 1-216-296-11 SHORT CHIP 0
R3101 1-219-365-11 SHORT CHIP 0
R3109 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3111 1-219-365-11 SHORT CHIP 0
R3145 1-216-296-11 SHORT CHIP 0
R3148 1-216-864-11 SHORT CHIP 0
R3153 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3154 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3155 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3156 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
AMP
Note: When the IC3102 and IC3302 on the AMP board are replaced, spread the
compound referring to “NOTE OF REPLACING THE IC3102 and IC3302 ON THE
AMP BOARD AND THE COMPLETE AMP BOARD” on servicing notes (page 10).
Ver. 1.2
