Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
9191
IC5902 6-705-313-01 IC S-T111B50MC-OHJTFG
IC5903 6-712-384-01 IC TC74VHC4052AFT (EK)
IC5904 6-710-554-01 IC PCM1808PWR
IC5905 6-715-041-01 IC TC7SZ125FU, RSOYJ
IC6301 A-1857-997-A IC R5F3650KCDFB (for SERVICE)
IC6303 6-713-333-01 IC PST8429UL
IC6305 6-702-302-01 IC TK11133CSCL-G
IC6401 6-713-560-01 IC MFI341S2162
(EXCEPT E190, E290/E490/E690: RU)
IC8001 (Not supplied) IC CS8422
< JACK >
J5901 1-780-853-11 JACK, PIN 2P (AUDIO IN L/R)
J6401 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L303 1-457-995-11 INDUCTOR 10uH
L304 1-457-771-11 INDUCTOR 2.2uH
L305 1-400-789-21 INDUCTOR 2.2uH
L306 1-400-789-21 INDUCTOR 2.2uH
L5301 1-400-789-21 INDUCTOR 2.2uH
L5302 1-457-995-11 INDUCTOR 10uH
L6402 1-412-982-21 INDUCTOR 1.8uH
< CONTACT TERMINAL >
PT303 1-780-945-11 TERMINAL, CONTACT
PT304 1-780-945-11 TERMINAL, CONTACT
< TRANSISTOR >
Q302 6-553-007-01 TR PMG85XP
Q305 6-552-430-01 TR DRC5114E0L
Q310 6-552-430-01 TR DRC5114E0L
Q311 6-553-007-01 TR PMG85XP
Q312 6-552-433-01 TR DRC5115E0L
Q702 6-551-714-01 TR INK0001AC1-T112-1
Q5301 6-552-430-01 TR DRC5114E0L
Q5901 6-551-690-01 TRANSISTOR RT3N11M-TP-1
Q5902 6-552-217-01 TR RTM001P02T2L (RU)
Q5903 6-552-433-01 TR DRC5115E0L (RU)
Q6301 6-552-408-01 TR DSC500100L
< RESISTOR >
R102 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R103 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R106 1-218-941-81 METAL CHIP 100 5% 1/16W
R108 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R110 1-216-864-11 SHORT CHIP 0
R206 1-218-941-81 METAL CHIP 100 5% 1/16W
R207 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R302 1-216-295-91 SHORT CHIP 0
R327 1-218-953-11 METAL CHIP 1K 5% 1/16W
* R330 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
* R331 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
* R332 1-250-499-11 METAL CHIP 1.5K 1% 1/16W
R333 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R334 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R335 1-208-859-81 METAL CHIP 68 0.5% 1/16W
* R336 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R340 1-218-953-11 METAL CHIP 1K 5% 1/16W
R341 1-216-864-11 SHORT CHIP 0
R342 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R343 1-218-953-11 METAL CHIP 1K 5% 1/16W
* R370 1-250-499-11 METAL CHIP 1.5K 1% 1/16W
R371 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R374 1-218-971-11 METAL CHIP 33K 5% 1/16W
R375 1-218-971-11 METAL CHIP 33K 5% 1/16W
R376 1-218-953-11 METAL CHIP 1K 5% 1/16W
R378 1-218-953-11 METAL CHIP 1K 5% 1/16W
R390 1-218-971-11 METAL CHIP 33K 5% 1/16W
R391 1-218-971-11 METAL CHIP 33K 5% 1/16W
R392 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R393 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R404 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R405 1-218-977-11 METAL CHIP 100K 5% 1/16W
R516 1-218-990-81 SHORT CHIP 0
R519 1-218-965-11 METAL CHIP 10K 5% 1/16W
R523 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R609 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R734 1-218-953-11 METAL CHIP 1K 5% 1/16W
R735 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R736 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R738 1-218-953-11 METAL CHIP 1K 5% 1/16W
R743 1-218-933-11 METAL CHIP 22 5% 1/16W
R744 1-218-933-11 METAL CHIP 22 5% 1/16W
R749 1-218-973-11 METAL CHIP 47K 5% 1/16W
R805 1-208-920-81 METAL CHIP 24K 0.5% 1/16W
R1002 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1008 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1010 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1012 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1014 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1016 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1018 1-218-941-81 METAL CHIP 100 5% 1/16W
R1019 1-218-941-81 METAL CHIP 100 5% 1/16W
R1020 1-218-941-81 METAL CHIP 100 5% 1/16W
R1021 1-218-941-81 METAL CHIP 100 5% 1/16W
R1022 1-218-990-81 SHORT CHIP 0
R1023 1-218-990-81 SHORT CHIP 0
R1028 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1033 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1036 1-218-990-81 SHORT CHIP 0
R1037 1-218-990-81 SHORT CHIP 0
R1038 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1110 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1112 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1120 1-250-535-11 METAL CHIP 47K 1% 1/16W
R1121 1-250-531-11 METAL CHIP 33K 1% 1/16W
R1134 1-250-519-11 METAL CHIP 10K 1% 1/16W
R1153 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1191 1-250-512-11 METAL CHIP 5.1K 1% 1/16W
R1192 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R1199 1-218-990-81 SHORT CHIP 0
R1210 1-248-476-11 RES-CHIP 0.16 1% 1/3W
R1213 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1214 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1215 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1216 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1217 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1218 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5301 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
MB148
Note: IC8001 on the MB148 board cannot exchange with single.
When this part is damaged, exchange the complete mounted
board.
Ver. 1.1
