Sony HBD-E290 - How to Bend FFC

HBD-E190/E290/E490/E690
13
2-2. HOW TO BEND FFC
wire (flat type) (13 core), length 320 mm (Ref. No. 55)
: Mountain fold
: Valley fold
wire (flat type) (30 core), length 130 mm (Ref. No. 108)
MB148 board
(CN6303)
PANEL board
(CN02)
25 mm
130 mm
45º 45º
35 mm
250 mm
The upper side
is contact side.
MB148 board
(CN5904)
The upper side
is contact side.
The upper side
is contact side.
wire (flat type) (7 core), length 65 mm (Ref. No. 105)
15 mm
25 mm
25 mm
MB148 board
(CN5902)
TUNER2 board
(CN101)
The upper side
is contact side.
The upper side
is contact side.
45º
AMP board
(CN3503)
The upper side
is contact side.
flexible flat cable (45 core), length 244 mm (Ref. No. 207)
wire (flat type) (5 core), length 265 mm (Ref. No. 208)
17 mm 60 mm 38 mm 24 mm 43 mm 62 mm
55 mm
93 mm
45º
MB148 board
(CN1101)
The upper side
is contact side.
The upper side
is contact side.
BD drive
(BPX-7)
15 mm
105 mm
45º 45º
9 mm 54 mm 138 mm
64 mm
MB148 board
(CN1270)
The lower side
is contact side.
The lower side
is contact side.
71 mm
73 mm
45º 45º
BD drive
(BPX-7)
131 mm
wire (flat type) (9 core), length 245 mm (Ref. No. 206)
38 mm 41 mm 13 mm 110 mm
30 mm
MB148 board
(CN1260)
The lower side
is contact side.
The lower side
is contact side.
33 mm
71 mm
BD drive
(BPX-7)
120 mm
45º45º 45º
13 mm
