SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-3. LEFT PANEL, RIGHT PANEL
(Page 14)
SET
2-2. HOW TO BEND FFC
(Page 13)
2-11. OPTICAL PICK-UP BLOCK (KEM480AAA),
WIRE (FLAT TYPE)
(Page 19)
2-6. TOP CHASSIS, KARAOKE BOARD (RU),
POWER KEY BOARD, PANEL BOARD
(Page 16)
2-10. AMP BOARD
(Page 18)
2-9. SWITCHING REGULATOR (SWR1)
(Page 18)
2-7. BD DRIVE (BPX-7)
(Page 17)
2-4. LOADING PANEL
(Page 14)
2-8. MB148 BOARD
(Page 17)
2-5. TOP PANEL, FRONT PANEL ASSY
(Page 15)
