Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
9393
R6341 1-218-941-81 METAL CHIP 100 5% 1/16W
R6342 1-218-990-81 SHORT CHIP 0
R6343 1-218-970-11 METAL CHIP 27K 5% 1/16W
R6345 1-218-990-81 SHORT CHIP 0 (RU)
R6347 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6348 1-218-941-81 METAL CHIP 100 5% 1/16W
R6350 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6352 1-218-965-11 METAL CHIP 10K 5% 1/16W
(RU)
R6355 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6356 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6357 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6358 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6359 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6360 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6361 1-218-973-11 METAL CHIP 47K 5% 1/16W
* R6366 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
R6367 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6368 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6369 1-218-973-11 METAL CHIP 47K 5% 1/16W
R6370 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6371 1-218-941-81 METAL CHIP 100 5% 1/16W
R6372 1-218-941-81 METAL CHIP 100 5% 1/16W
R6374 1-218-977-11 METAL CHIP 100K 5% 1/16W
R6377 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R6382 1-208-709-11 METAL CHIP 12K 0.5% 1/16W
R6384 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6388 1-218-941-81 METAL CHIP 100 5% 1/16W
R6389 1-218-977-11 METAL CHIP 100K 5% 1/16W
(EXCEPT RU)
R6390 1-218-990-81 SHORT CHIP 0
R6391 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6392 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6393 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R6394 1-218-941-81 METAL CHIP 100 5% 1/16W
R6395 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R6396 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R6397 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R6398 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R6403 1-218-990-81 SHORT CHIP 0
R6406 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R6407 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R6411 1-218-990-81 SHORT CHIP 0
(EXCEPT E190, E290/E490/E690: RU)
R6416 1-218-990-81 SHORT CHIP 0
R6420 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R6421 1-218-990-81 SHORT CHIP 0
R8002 1-218-941-81 METAL CHIP 100 5% 1/16W
R8003 1-218-941-81 METAL CHIP 100 5% 1/16W
R8005 1-218-989-11 METAL CHIP 1M 5% 1/16W
R8006 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R8007 1-218-941-81 METAL CHIP 100 5% 1/16W
R8008 1-218-937-11 METAL CHIP 47 5% 1/16W
R8009 1-218-941-81 METAL CHIP 100 5% 1/16W
R8010 1-218-937-11 METAL CHIP 47 5% 1/16W
R8016 1-218-967-11 METAL CHIP 15K 5% 1/16W
R8017 1-218-967-11 METAL CHIP 15K 5% 1/16W
R8029 1-218-941-81 METAL CHIP 100 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1001 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1002 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6301 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6304 1-234-372-11 RES, NETWORK 100 (1005X4)
< THERMISTOR >
TH6301 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X401 1-814-278-11 VIBRATOR, CRYSTAL (27MHz)
X6301 1-795-313-21 VIBRATOR, CERAMIC (8MHz)
X8001 1-814-130-11 QUARTZ CRYSTAL UNIT (24.576MHz)
************************************************************
A-1848-680-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C02 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C03 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C04 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C05 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C06 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C08 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C10 1-114-324-11 CERAMIC CHIP 0.022uF 10% 50V
C13 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C14 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C15 1-119-772-91 ELECT 47uF 20% 35V
C17 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C18 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C20 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C25 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C27 1-126-176-11 ELECT 220uF 20% 10V
C30 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C31 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C40 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C43 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN02 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN03 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN04 1-819-866-11 USB CONNECTOR (A) (
)
< DIODE >
D03 6-501-579-01 DIODE MC2837
D04 6-501-579-01 DIODE MC2837
D05 6-503-012-01 DI DZ2J04300L
< IC >
IC01 6-715-891-01 IC MM3464A50NRE
IC02 6-715-134-01 IC MM3404A33URE
IC03 6-718-162-01 IC PT6315LQ
IC30 6-600-665-01 IC GP1UE27XK0VF
< JUMPER RESISTOR >
JR01 1-216-864-11 SHORT CHIP 0
JR02 1-216-864-11 SHORT CHIP 0
JR03 1-216-864-11 SHORT CHIP 0
JR04 1-216-864-11 SHORT CHIP 0
JR06 1-216-864-11 SHORT CHIP 0
MB148 PANEL
Ver. 1.2
To Next Page
