Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E190/E290/E490/E690
9595
Note: Wires (fl at type) for service is all straight.
Please bend it referring go “HOW TO BEND FFC” on page
13 when you install it in the unit.
TUNER2
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
< IC >
IC101 6-717-989-01 IC RZ5B701-0001E2 (EXCEPT AEP, UK, SAF)
IC101 6-717-990-01 IC RZ5B701-0002E2 (AEP, UK, SAF)
IC102 6-715-134-01 IC MM3404A33URE
< COIL >
L103 1-481-524-11 INDUCTOR 10uH
L104 1-481-521-11 INDUCTOR 1uH
L105 1-481-521-11 INDUCTOR 1uH
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-801-11 METAL CHIP 22 5% 1/10W
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-296-11 SHORT CHIP 0
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
MISCELLANEOUS
**************
54 1-968-135-11 HARNESS (USB)
55 1-828-333-61 WIRE (FLAT TYPE) (13 CORE)
0 102 1-777-071-23 CORD, POWER (PX)
0 102 1-777-071-83 CORD, POWER
(AEP, RU, SAF, SP, MX6, E3, E32, E15)
0 102 1-835-068-21 CORD, POWER (AUS)
0 102 1-837-308-11 CORD, POWER-SUPPLY (CND)
0 102 1-837-309-21 CORD, POWER-SUPPLY (UK, EA)
0 102 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 102 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 102 1-839-012-11 CORD, POWER-SUPPLY (E12)
0 102 1-839-940-21 POWER-SUPPLY CORD (TH)
0 103 1-569-008-33 ADAPTOR, CONVERSION (MX6, PX, E32)
105 1-828-296-61 WIRE (FLAT TYPE) (7 CORE)
108 1-828-799-51 WIRE (FLAT TYPE) (30 CORE)
202 A-1850-153-C LOADING FOR SERVICE (BPX-7)
0 205 8-820-452-03 DEVICE, OPTICAL KEM480AAA/C2RP1
206 1-839-608-61 WIRE (FLAT TYPE) (9 CORE)
207 1-839-609-11 FLEXIBLE FLAT CABLE (45 CORE)
208 1-839-611-61 WIRE (FLAT TYPE) (5 CORE)
0 M1 1-855-134-11 FAN, DC
0 SWR1 1-474-368-11 SWITCHING REGULATOR (3L382W-1)
(E290: AEP, UK, SAF, SP, AUS, TW, TH, CH/
E490: CND, AEP, UK, SP, TW, TH, CH/
E690: AEP, SP, AUS, TH)
0 SWR1 1-474-368-21 SWITCHING REGULATOR (3L382W)
(E290: RU, E3, EA, PX, E12, E32/
E490: RU, MX6, E3, EA, E12, E15/
E690: RU, E3, EA, E12, E15)
0 SWR1 1-474-369-11 SWITCHING REGULATOR (3L383W-1)
(E190: CND, AEP, UK, SAF, SP, AUS)
Ver. 1.4
0 SWR1 1-474-369-21 SWITCHING REGULATOR (3L383W)
(E190: RU, MX6)
