Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E370/E470/E570/E870/T57
106
C2309 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C2322 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2324 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2364 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2371 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2400 1-117-681-11 ELECT CHIP 100uF 20% 16V
C2401 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2402 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2403 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2404 1-114-130-11 CERAMIC CHIP 1uF 10% 6.3V
C2405 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2416 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C2417 1-114-214-81 CERAMIC CHIP 470PF 5% 50V
C2418 1-112-775-11 CERAMIC CHIP 0.0022uF 10% 50V
C2419 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2420 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C2421 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C2422 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C2432 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C2433 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C2438 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2440 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2450 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2460 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2470 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C2481 1-114-553-11 CERAMIC CHIP 10uF 10% 16V
C2486 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C2491 1-114-553-11 CERAMIC CHIP 10uF 10% 16V
C2495 1-114-553-11 CERAMIC CHIP 10uF 10% 16V
C2499 1-114-553-11 CERAMIC CHIP 10uF 10% 16V
< CONNECTOR >
CN303 1-766-383-21 PIN, CONNECTOR (1.5mm) (SMD) 12P
CN601 1-573-768-21 PIN, CONNECTOR (1.5mm) (SMD) 5P
CN602 1-573-768-61 PIN, CONNECTOR (1.5mm) (SMD) 5P
CN701 1-820-735-31 HDMI CONNECTOR (HDMI ARC OUT)
CN901 1-779-332-51 CONNECTOR, FFC/FPC 16P
CN902 1-779-333-51 CONNECTOR, FFC/FPC 18P
CN1102 1-573-806-21 PIN, CONNECTOR (1.5mm) (SMD) 6P
CN1201 1-819-875-31 ETHERNET CONNECTOR (8P) (LAN (100))
CN1401 1-822-601-51 CONNECTOR, FFC/FPC (ZIF) 45P
CN1505 1-794-341-51 CONNECTOR, FFC/FPC 27P
CN2460 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN2470 1-794-362-51 CONNECTOR, FFC/FPC 5P
< DIODE >
D302 6-502-964-01 DIODE DZ2J047M0L
D303 6-502-248-01 DIODE KDZTR3.9B
D304 6-502-248-01 DIODE KDZTR3.9B
D601 6-502-961-01 DIODE DA2J10100L
D602 6-502-961-01 DIODE DA2J10100L
D603 6-500-701-01 DIODE PGB1010603NR
D604 6-500-701-01 DIODE PGB1010603NR
D605 6-500-701-01 DIODE PGB1010603NR
D606 6-500-701-01 DIODE PGB1010603NR
< RESISTOR >
FB2300 1-244-161-81 METAL CHIP 2.2 5% 1/16W
FB2403 1-244-161-81 METAL CHIP 2.2 5% 1/16W
FB2481 1-216-864-11 SHORT CHIP 0
< FILTER >
FL301 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL302 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 (Not supplied) IC CXD9983GG (E370: US/E470/E570/T57)
IC101 (Not supplied) IC CXD9984GG (E370: CND, AEP, UK/E870)
IC104 (Not supplied) IC K4T1G164QE-HCF8
IC105 (Not supplied) IC K4T1G164QE-HCF8
IC204 (Not supplied) IC K4T1G164QE-HCF8
IC205 (Not supplied) IC K4T1G164QE-HCF8
IC303 6-709-932-01 IC MM3141CNRE
IC307 (Not supplied) IC MM3293DNRE
IC308 6-714-889-01 IC MP2301ENE-LF-Z
IC309 6-714-911-01 IC TPS54325PWPR
IC310 6-714-911-01 IC TPS54325PWPR
IC311 (Not supplied) IC BD3539NUX-TR
IC312 6-714-890-01 IC MM1855AHBE
IC501 (Not supplied) IC K9GAG08U0D-PCB0T
IC502 (Not supplied) IC MX25L1605DM2I-12G
IC601 6-712-613-01 IC SI-3010KM-TLS
IC602 6-712-613-01 IC SI-3010KM-TLS
IC701 6-709-888-01 IC TC7WHU04FK (T5RSOYF
IC704 6-702-302-01 IC TK11133CSCL-G
IC705 6-705-337-01 IC TK11150CSCL-G
IC1001 6-711-237-01 IC NJM2878F3-33 (TE2)
IC1002 6-714-112-01 IC NJM2828F3-05
IC1003 6-714-834-01 IC MM1797CVBE
IC1101 6-713-555-01 IC MFI341S2161
IC1201 6-712-663-11 IC LAN8700C-AEZG-CTI
IC1451 6-713-929-01 IC BD35630HFV-TR
IC2301 6-714-902-01 IC TPIC1391DBTRG4
IC2401 6-714-901-01 IC TPIC1405DFDRG4
< JACK >
J904 1-822-993-11 JACK, PIN
(VIDEO OUT, COMPONENT VIDEO OUT)
< COIL >
L301 1-457-735-11 INDUCTOR 10uH
L302 1-400-789-21 INDUCTOR 2.2uH
L303 1-457-771-11 INDUCTOR 2.2uH
L304
1-457-771-11 INDUCTOR 2.2uH
L305 1-400-789-21 INDUCTOR 2.2uH
L306 1-400-789-21 INDUCTOR 2.2uH
L603 1-414-840-21 INDUCTOR 10nH
L604 1-414-840-21 INDUCTOR 10nH
L605 1-414-840-21 INDUCTOR 10nH
L606 1-414-840-21 INDUCTOR 10nH
L607 1-457-223-11 COMMON MODE CHOKE COIL
L608 1-457-223-11 COMMON MODE CHOKE COIL
L1201 1-457-223-11 COMMON MODE CHOKE COIL
L1202 1-457-223-11 COMMON MODE CHOKE COIL
L2322 1-481-551-21 INDUCTOR 1.5uH
L2324 1-481-551-21 INDUCTOR 1.5uH
< FUSE >
0 PS301 1-523-094-31 FUSE (2A/50V)
MB-134
Note: IC101, IC104, IC105, IC204, IC205, IC307, IC311, IC501 and
IC502 on the MB-134 board cannot exchange with single. When
these parts are damaged, exchange the entire mounted board.
