6. Diag (Audio Input Test)
This screen performs audio input test.
Screen 1: Selects the test category
Operation:
[<]/[,] Selects the category
[m]/[3] Moves to the selected category
Screen 2: Select Audio Input Test
Operation:
[M]/[m] Select test
[3] Start/stop input sound
[RETURN] Returns to the selection of test category
• Digital Input
Input : SPDIF (optical, 48 kHz, 2 ch only).
Sound output : Speaker (2 ch).
• Analog Input
Input : Line In (2 ch).
Sound output : Speaker (2 ch).
 Diag
Category: Audio Input Test
HELP: [UP][ENT][RET]
 Diag
Category: Audio Input Test
Device: Digital Input
Analog Input
[ENT] Start Input Sound
HELP: [UP] [ENT] [RET]
(Screen 1)
(Screen 2)
7. Diag (Wireless LAN Test)
This screen performs wireless LAN test.
Note: Not used for the servicing.
8. Log: Error Log (Output of each Log)
This screen displays the contents of each log.
Note: Do not refer to the displayed date.
Screen 1: Selects log
Operation:
[1]/[
3] Moves to the Error Log output screen
[RETURN] Returns to the top menu of the service mode
Screen 2: Displays the Error Log
Operation:
[
<
] Returns to the previous page
[
,
] Moves to the next page
[RETURN] Returns to the screen (screen 1) that selects the log
type
[RED] Writes the log contents to an USB memory device
• Viewing the log display
Error Log:
001 08/01/01 00: 53: 19: [ErrCode: 080400000000]
[Number (starting from old log) ] [date] [time] [error code]
About copying log to USB memory device:
Press the [RED] button in each log display screen with the USB
memory device inserted into the set
Note: Please do not press the [RED] button immediately after USB mem-
ory is inserted.
Please do not pull out USB memory immediately after the [RED]
button was pressed.
Error Log:
When “getErrLogFile.trm fi le” exists in the USB memory de-
vice, errlog.log fi le is output.
 Select Log
HELP : [DOWN][ENT][(NUM)]
 Error Log
001 08/01/01 00: 53: 19: [ErrCode: 080400000000]
002 08/01/01 00: 53: 45: [ErrCode: 080400252100]
003 08/01/01 00: 54: 00: [ErrCode: 080400005555]
:
:
[1] Error Log
(Screen 1)
(Screen 2)
