13. Drive
This menu is used to operate the drive using drive-related diagnos-
tic and tools.
Screen 1: Selecting items under *Service Menu

Service Menu
[1] Diag
[2] Log
[3] Factory Initialize
[4] Network
[5] Version Up
[6] System Information
[7] EMC Test Mode
[8] Drive
(Screen 1)
Screen 2: Selecting items under *Drive
Drive
[1]Drive OP data Write
[2]Servo Parameter Check Menu
[3]Servo Signal Check Menu
[4]S - Curve Check Menu
[5]Readability Check Menu
[6]OP Position Check Menu
[7]OP Check Menu
[8]Load Eject Aging
[9]Spindle Control Check Menu
[10]FA Test Mode

(Screen 2)
Operation:
[
M
]/[
m
] Move the cursor up and down
[3] Open the selected cursor item
[RETURN] Returns to the top menu of the service mode
• Test item list
[1] Drive OP data Write
[2] Servo Parameter Check Menu
[3] Servo Signal Check Menu
[4] S-Curve Check Menu
[5] Readability Check Menu
[6] OP Position Check Menu
[7] OP Check Menu
[8] Load Eject Aging
[9] Spindle Control Check Menu
[10] FA Test Mode
Screen 3: *Drive OP data Write
Purpose: Write OP data into fl ash IC
[
M
]/[
m
] Move the cursor up and down
[
3] Start the selected cursor item
[RETURN] Returns to the top menu of the service mode
Drive OP data Write
Insert USB StorageDevice ...
Remove DISC and Close tray.
[1]Disc: Eject
[ENT] Start

(Screen 3)
Screen 4: *Servo Parameter Check Menu (Not Used)
(Screen 4)

Servo Parameter Check Menu
[1] Disc: Eject
[2] Show Parameters
Not used for the servicing.
Press the [RETURN] button if having entered this mode.
Screen 5: *Servo Signal Check Menu (Not Used)
(Screen 5)
Servo Signal Check Menu
[1] Disc: Eject
[2] Servo Signal Monitor out: OFF
[3] RTADJ: OFF
[4] FocusBias: 0000
[5] SA -Act.move: FWD 00 step
[6] Pl Level: 0000
[7] RF Level: 0000
[8] TRV Level: 0000
[9] Current FB: 0000 SA: 0000

Not used for the servicing.
Press the [RETURN] button if having entered this mode.
