Sony HBD-E370 - Page 85

HBD-E370/E470/E570/E870/T57
85
Pin No. Pin Name I/O Description
AT16 A_RDQ5 I/O Two-way data bus with the SD-RAM
AT18 A_RDQM0 O Data mask signal output to the SD-RAM
AT20 A_RDQ11 I/O Two-way data bus with the SD-RAM
AT22 DVSS - Ground terminal
AT24 A_RA11 O Address signal output to the SD-RAM
AT26 A_RA1 O Address signal output to the SD-RAM
AT28 A_RBA2 O Bank address signal output to the SD-RAM
AT30 A_RVREF I Reference voltage (+0.9V) input terminal for the SD-RAM
AT32 A_RDQ23 I/O Two-way data bus with the SD-RAM
AT34 DVSS - Ground terminal
AT36 DVSS - Ground terminal
AT38 B_RDQ5 I/O Two-way data bus with the SD-RAM
AT40 B_RDQS0 O Data strobe signal (positive) output to the SD-RAM
AT42 B_RDQS0B O Data strobe signal (negative) output to the SD-RAM
AU1 AVDD33_RTC - Power supply terminal (+3.3V)
AU3 AVSS33_RTC - Ground terminal
AU5 AVDD33_SACD - Power supply terminal (+3.3V)
AU7 AVDD33_ST - Power supply terminal (+3.3V)
AU9 AVSS12_ST2 - Ground terminal
AU11 EEPWRQ - Not used
AU13 VCC3IO_1 - Power supply terminal (+3.3V)
AU15 A_RDQ3 I/O Two-way data bus with the SD-RAM
AU17 DVSS - Ground terminal
AU19 A_RDQ9 I/O Two-way data bus with the SD-RAM
AU21 DVSS - Ground terminal
AU23 A_RCASB O Column address strobe signal output to the SD-RAM
AU25 DVSS - Ground terminal
AU27 A_RBA1 O Bank address signal output to the SD-RAM
AU29 DVSS - Ground terminal
AU31 A_RDQ21 I/O Two-way data bus with the SD-RAM
AU33 DVSS - Ground terminal
AU35 A_RDQM3 O Data mask signal output to the SD-RAM
AU37 A_RDQ27 I/O Two-way data bus with the SD-RAM
AU39 DVSS - Ground terminal
AU41 B_RDQ3 I/O Two-way data bus with the SD-RAM
AU43 B_RDQ2 I/O Two-way data bus with the SD-RAM
AV2 FE_JRTCLK - Not used
AV4 AVSS33_SACD - Ground terminal
AV6 AVDD12_SRX1 - Power supply terminal (+1.2V)
AV8 AVSS12_ST1 - Ground terminal
AV10 AVDD12_ST - Power supply terminal (+1.2V)
AV12 GPIO6 O UPG status signal output to the system controller
AV14 SDA I/O Two-way data bus with the EEPROM
AV16 A_RDQ0 I/O Two-way data bus with the SD-RAM
AV18 A_RDQM1 O Data mask signal output to the SD-RAM
AV20 A_RDQ14 I/O Two-way data bus with the SD-RAM
AV22 A_RA13 O Address signal output to the SD-RAM
AV24 A_RCSB O Chip select signal output to the SD-RAM
AV26 A_RA2 O Address signal output to the SD-RAM
AV28 A_RA5 O Address signal output to the SD-RAM
AV30 NC - Not used
AV32 A_RDQ16 I/O Two-way data bus with the SD-RAM
AV34 A_RDQM2 O Data mask signal output to the SD-RAM
AV36 A_RDQ25 I/O Two-way data bus with the SD-RAM
AV38 A_RDQ30 I/O Two-way data bus with the SD-RAM
AV40 VCC2IO - Power supply terminal (+1.8V)
AV42 VCC2IO - Power supply terminal (+1.8V)
AW1 FE_JTMS - Not used
AW3 FE_JTDI - Not used
AW5 AVDD12_STX1 - Power supply terminal (+1.2V)
