52
HCD-BC150/BC250
Pin No. Pin Name I/O Description
117 RFIN I RF signal input from the DVD/CD RF amplifier
118, 119 VCCA5, VCCA4 — Power supply terminal (+3.3V) (analog system)
120 VCOR1 — VCO oscillating range setting resistor connected terminal
121 VCOIN I VCO input terminal
122, 123 GNDA4, GNDA3 — Ground terminal (analog system)
124 LPF5 O Signal output from the operation amplifier from PLL loop filter
125 VC1 I Middle point voltage (+1.65V) input terminal
126, 127 LPF2, LPF1 I Inverted signal input to the operation amplifier from PLL loop filter
128, 129 VCCA3, VCCA2 — Power supply terminal (+3.3V) (analog system)
130 PD0 O Signal output from the charge pump for phase comparator
131 PDHVCC I Middle point voltage input terminal for RF PLL
132 FDO O Signal output from the charge pump for frequency comparator
133, 134 GNDA2, GNDA1 — Ground terminal (analog system)
135 SPO O Spindle motor control signal output
136 VC2 I Middle point voltage (+1.65V) input terminal
137 MDIN2 I Spindle motor servo drive signal input
138 MDIN1 I MDP input terminal
139 VCCA1 — Power supply terminal (+3.3V) (analog system)
140 CLVS O Control signal output for selection the spindle control filter constant at CLVS
141 VSS — Ground terminal (digital system)
142 MDSOUT O Frequency error output terminal of internal CLV circuit
143 VDD — Power supply terminal (+3.3V) (digital system)
144 MDPOUT O Phase error output terminal of internal CLV circuit
145 DEFECT I Defect signal input terminal (conected to ground terminal)
146 GSCOR I Guard subcode sync (S0+S1) detection signal input from the digital signal processor
147 EXCK O Subcode serial data reading clock signal output to the digital signal processor
148 SBIN I Subcode serial data input from the digital signal processor
149 VSS — Ground terminal (digital system)
150 SCOR I Subcode sync (S0+S1) detection signal input from the digital signal processor
151 WFCK I Write frame clock signal input from the digital signal processor
152 VDD5V — Power supply terminal (+5V)
153 XRCI I RAM overflow signal input terminal (conected to ground terminal)
154 VDDS — Power supply terminal (+5V) (digital system)
155 C2PO I C2 pointer signal input from the digital signal processor
156 VDD — Power supply terminal (+3.3V) (digital system)
157 DBCK O Bit clock signal (2.8224 MHz) output terminal Not used
158 BCLK I Bit clock signal (2.8224 MHz) input from the digital signal processor
159 DDAT O PCM data output terminal Not used
160 MDAT I Serial data input from the digital signal processor
161 VSS — Ground terminal (digital system)
162 DLRC O L/R sampling clock signal (44.1 kHz) output terminal Not used
163 LRCK I L/R sampling clock signal (44.1 kHz) input from the digital signal processor
164 XRST I Reset signal input from the mechanism controller “L”: reset
165 IFS0 I Interface selection signal input terminal Fixed at “L” in this set
166 IFS1 I Interface selection signal input terminal Fixed at “H” in this set
167 XTAL I 33.8688 MHz clock signal input terminal
168 VSS — Ground terminal (digital system)
Ver 1.3
