Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-CX4iP/CX5iP
50
C771 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C772 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C773 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C780 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C781 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C782 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C783 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C784 1-100-623-91 CERAMIC CHIP 0.1uF 10% 100V
C785 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C790 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C791 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C792 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V
C793 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C797 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C1101 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1114 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1118 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1119 1-112-342-91 CERAMIC CHIP 10uF 20% 10V
C1161 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1228 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1229 1-114-219-21 CERAMIC CHIP 1uF 10% 10V
C1235 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1242 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1265 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1274 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1275 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C1282 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C1283 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
CN301 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN471 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN491 1-764-250-21 PIN, CONNECTOR (PC BOARD) 4P (CX5iP)
CN671 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN690 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN701 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN702 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
CN1100 1-778-692-51 CONNECTOR, FFC/FPC 21P
CN1161 1-784-366-51 CONNECTOR, FFC/FPC 7P
CN1210 1-785-728-21 PIN (PC BOARD), CONNECTOR 7P
CN1220 1-784-370-51 CONNECTOR, FFC/FPC 11P
CN1235 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN1240 1-784-365-51 CONNECTOR, FFC/FPC 5P
CN1250 1-784-368-51 CONNECTOR, FFC/FPC 9P
< DIODE >
D302 6-503-038-01 DIODE DZ2J27000L
D303 6-503-028-01 DIODE DZ2J130M0L
D304 6-503-028-01 DIODE DZ2J130M0L
D305 6-502-969-01 DIODE DZ2J06800L
D306 6-502-961-01 DIODE DA2J10100L
D307 6-502-990-01 DIODE SJPJ-L3VL
D308 6-502-990-01 DIODE SJPJ-L3VL
D309 6-502-990-01 DIODE SJPJ-L3VL
D310 6-501-119-01 DIODE RR264M-400
D311 6-501-568-01 DIODE RB521CS-30T2R
D312 6-501-568-01 DIODE RB521CS-30T2R
D313 6-502-961-01 DIODE DA2J10100L
D471 6-503-013-01 DIODE DZ2J043M0L
D472 6-503-013-01 DIODE DZ2J043M0L
D491 6-503-013-01 DIODE DZ2J043M0L (CX5iP)
D492 6-503-013-01 DIODE DZ2J043M0L (CX5iP)
D617 6-502-961-01 DIODE DA2J10100L
D618 6-501-119-01 DIODE RR264M-400
< EARTH TERMINAL >
ET302 1-780-482-11 EARTH TERMINAL
< FERRITE BEAD >
FB301 1-400-089-21 INDUCTOR (EMI FERRITE) (2012)
FB302 1-400-089-21 INDUCTOR (EMI FERRITE) (2012)
< IC >
IC101 A-1816-172-A IC R5F364AEDFA (for SERVICE)
IC301 6-716-575-01 IC TPS54331DR
IC303 6-705-160-01 IC S-812C33AMC-C2NT2G
IC304 6-716-575-01 IC TPS54331DR
IC306 6-716-575-01 IC TPS54331DR
IC314 8-759-338-95 IC NJM2903V (TE2)
IC470 6-711-583-01 IC TS3USB221RSER (CX5iP)
IC501 6-717-314-01 IC BU94604KV-E2
IC580 6-715-164-01 IC TPS2553DBVR
IC590 6-715-164-01 IC TPS2553DBVR (CX5iP)
IC601 6-715-490-01 IC BU9408KS2
IC681 6-710-554-01 IC PCM1808PWR
IC682 8-759-523-03 IC TC74HC4066AFT (EL)
IC701 (Not supplied) IC BD5446EFV-E2
IC750 6-715-344-01 IC MM3404A50URE
IC1270 6-713-362-01 IC MFI341S2164
< COIL >
L303 1-416-758-21 CHOKE COIL 22uH
L304 1-416-758-21 CHOKE COIL 22uH
L305 1-416-758-21 CHOKE COIL 22uH
L698 1-469-967-21 INDUCTOR 10uH
L699 1-469-967-21 INDUCTOR 10uH
L760 1-457-387-11 INDUCTOR 22uH
L780 1-457-387-11 INDUCTOR 22uH
L1118 1-460-402-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q301 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q302 6-551-696-01 TRANSISTOR ISA1235AC1-T112-1EF
Q303 6-551-696-01 TRANSISTOR ISA1235AC1-T112-1EF
Q304 6-551-932-01 TRANSISTOR LSS050P03FP8TB1
Q305 8-729-029-09 TRANSISTOR DTC143EUA-T106
Q306 6-551-933-01 TRANSISTOR LSS040P03FP8TB1
Q310 8-729-029-09 TRANSISTOR DTC143EUA-T106
Q311 6-551-933-01 TRANSISTOR LSS040P03FP8TB1
Q681 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q682 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q760 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q761 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q780 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q781 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
Q790 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1113 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q1114 6-551-067-01 FET RTF015P02TL
Q1242 8-729-038-37 TRANSISTOR RT1N141M-TP-1
MAIN
Note:
IC701 on the MAIN board cannot exchange with single. When
this part is damaged, exchange the complete mounted board.
To Next Page
