46
HCD-CX4iP/CX5iP
SECTION 6
ELECTRICAL PARTS LIST
AUDIO-JACK BOARD
****************
< CAPACITOR >
C1501 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1502 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1511 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C1512 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< DIODE >
D1509 6-500-848-01 DIODE MC2840-T112-1
< JACK >
J1501 1-815-629-21 JACK (AUDIO IN)
< RESISTOR >
R1501 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1508 1-216-864-11 SHORT CHIP 0
R1509 1-216-864-11 SHORT CHIP 0
R1511 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
A-1805-057-A BD94D-V BOARD, COMPLETE
***********************
< CAPACITOR >
C101 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C104 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C109 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C115 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C129 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C130 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C134 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C135 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C136 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C137 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C138 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C140 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C141 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C142 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C143 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C144 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C145 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C146 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C148 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C151 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C152 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C153 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C160 1-117-681-11 ELECT CHIP 100uF 20% 16V
C201 1-117-681-11 ELECT CHIP 100uF 20% 16V
C202 1-117-681-11 ELECT CHIP 100uF 20% 16V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C207 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C302 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C303 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C309 1-117-681-11 ELECT CHIP 100uF 20% 16V
C401 1-128-394-11 ELECT CHIP 220uF 20% 10V
C403 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C405 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C407 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD94D-V
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
BR : Brazilian model
CH : Chinese model
E2 : 120V AC area in E model
KR : Korean model
MX : Mexican model
RU : Russian model
SP : Singapore model
TW : Taiwan model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
AUDIO-JACK
