Sony HCD-CX4iP - Page 47

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-CX4iP/CX5iP
4747
< CONNECTOR >
CN202 1-784-833-51 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN301 1-770-425-51 CONNECTOR, FFC/FPC 16P
< IC >
IC101 6-712-082-01 IC TC94A70FG-101
IC201 6-714-504-01 IC MM3404A15URE
IC401 6-710-637-01 IC BA5826HFP-E2
< TRANSISTOR >
Q301 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR >
R101 1-216-864-11 SHORT CHIP 0
R103 1-216-813-11 METAL CHIP 220 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-857-11 METAL CHIP 1M 5% 1/10W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R110 1-216-295-91 SHORT CHIP 0
R115 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-833-11 METAL CHIP 10K 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R127 1-216-835-11 METAL CHIP 15K 5% 1/10W
R128 1-216-851-11 METAL CHIP 330K 5% 1/10W
R130 1-216-841-11 METAL CHIP 47K 5% 1/10W
R136 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R137 1-216-864-11 SHORT CHIP 0
R138 1-216-864-11 SHORT CHIP 0
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-809-11 METAL CHIP 100 5% 1/10W
R146 1-216-845-11 METAL CHIP 100K 5% 1/10W
R147 1-216-833-11 METAL CHIP 10K 5% 1/10W
R148 1-216-837-11 METAL CHIP 22K 5% 1/10W
R149 1-216-864-11 SHORT CHIP 0
R150 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-864-11 SHORT CHIP 0
R154 1-216-864-11 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-91 SHORT CHIP 0
R202 1-216-295-91 SHORT CHIP 0
R204 1-216-864-11 SHORT CHIP 0
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R213 1-216-809-11 METAL CHIP 100 5% 1/10W
R214 1-216-809-11 METAL CHIP 100 5% 1/10W
R215 1-216-809-11 METAL CHIP 100 5% 1/10W
R216 1-216-809-11 METAL CHIP 100 5% 1/10W
R217 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R304 1-218-446-11 METAL CHIP 1 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R411 1-216-864-11 SHORT CHIP 0
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
R416 1-216-864-11 SHORT CHIP 0
R417 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R418 1-216-833-11 METAL CHIP 10K 5% 1/10W
R419 1-216-835-11 METAL CHIP 15K 5% 1/10W
R420 1-216-864-11 SHORT CHIP 0
R421 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-814-450-11 QUARTZ CRYSTAL UNITS (16.9344MHz)
************************************************************
DC-JACK BOARD
*************
< CAPACITOR >
C1752 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< DIODE >
D1701 6-501-569-01 DIODE 1N5401-C352
< FUSE >
0 F1701 1-523-193-51 FUSE (3.15A/250V)
< JACK >
J1701 1-779-745-21 JACK, DC (DC IN 19.5V)
************************************************************
DRIVER BOARD
************
When the DRIVER board is damaged, exchange the CDM80BTK ASSY.
************************************************************
A-1816-181-A FL BOARD, COMPLETE
******************
4-154-640-01 SHEET (FL HOLDER), ADHESIVE
< CAPACITOR >
C601 1-125-972-91 ELECT 100uF 20% 16V
C602 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C632 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C647 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C648 1-128-131-11 ELECT 22uF 20% 50V
C651 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C652 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C653 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C654 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C655 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
BD94D-V DC-JACK DRIVER FL
