Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-CX4iP/CX5iP
48
C656 1-124-234-00 ELECT 22uF 20% 16V
C670 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C671 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C672 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C673 1-128-131-11 ELECT 22uF 20% 50V
C674 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C675 1-136-157-00 FILM 0.022uF 5% 50V
C676 1-124-234-00 ELECT 22uF 20% 16V
C678 1-165-621-91 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CN601 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D670 6-502-968-01 DIODE DZ2J062M0L
D671 6-500-334-01 DIODE MC2836-T112-1
D672 6-500-335-01 DIODE MC2838-T112-1
< IC >
IC601 6-711-008-01 IC PT6302LQ-010
< JUMPER RESISTOR >
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
< COIL >
L670 1-412-537-31 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND601 1-519-993-31 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q632 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q670 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R632 1-216-837-11 METAL CHIP 22K 5% 1/10W
R648 1-216-837-11 METAL CHIP 22K 5% 1/10W
R651 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R652 1-216-821-11 METAL CHIP 1K 5% 1/10W
R653 1-216-864-11 SHORT CHIP 0
R654 1-216-864-11 SHORT CHIP 0
R655 1-216-864-11 SHORT CHIP 0
R670 1-216-809-11 METAL CHIP 100 5% 1/10W
R671 1-216-809-11 METAL CHIP 100 5% 1/10W
R672 1-216-833-11 METAL CHIP 10K 5% 1/10W
R673 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R674 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R675 1-216-295-91 SHORT CHIP 0
R681 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R682 1-218-835-11 METAL CHIP 330 0.5% 1/10W
R683 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R684 1-218-843-11 METAL CHIP 680 0.5% 1/10W
R685 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R686 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R687 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R688 1-218-835-11 METAL CHIP 330 0.5% 1/10W
< SWITCH >
S680 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S681 1-762-875-21 SWITCH, KEYBOARD (
u
)
S682 1-762-875-21 SWITCH, KEYBOARD (
.
, TUNE –)
S683 1-762-875-21 SWITCH, KEYBOARD (
>
, TUNE +)
S684 1-762-875-21 SWITCH, KEYBOARD (VOL –)
S685 1-762-875-21 SWITCH, KEYBOARD (VOL +)
S686 1-762-875-21 SWITCH, KEYBOARD (
Z
)
S687 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S688 1-762-875-21 SWITCH, KEYBOARD (
x
)
< TRANSFORMER >
T670 1-445-890-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
A-1816-189-A IP BOARD, COMPLETE
******************
< CAPACITOR >
C852 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C853 1-116-100-11 ELECT CHIP 220uF 20% 6.3V
C854 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C855 1-164-870-11 CERAMIC CHIP 68PF 5% 50V
C856 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN851 1-820-701-11 PIN, CONNECTOR 30P
CN852 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D851 6-500-848-01 DIODE MC2840-T112-1
< RESISTOR >
R853 1-216-864-11 SHORT CHIP 0
R854 1-216-864-11 SHORT CHIP 0
R856 1-216-809-11 METAL CHIP 100 5% 1/10W
R857 1-216-864-11 SHORT CHIP 0
R859 1-216-295-91 SHORT CHIP 0
R860 1-216-295-91 SHORT CHIP 0
************************************************************
A-1816-178-A MAIN BOARD, COMPLETE (CX5iP: AEP)
A-1821-899-A MAIN BOARD, COMPLETE (CX4iP)
A-1824-634-A MAIN BOARD, COMPLETE (CX5iP: AUS)
A-1824-645-A MAIN BOARD, COMPLETE (CX5iP: BR)
A-1824-650-A MAIN BOARD, COMPLETE (CX5iP: E2, AR)
A-1832-646-A MAIN BOARD, COMPLETE (CX5iP: RU)
A-1832-667-A MAIN BOARD, COMPLETE (CX5iP: SP, TW)
A-1832-691-A MAIN BOARD, COMPLETE (CX5iP: KR)
A-1832-808-A MAIN BOARD, COMPLETE (CX5iP: CH)
A-1833-083-A MAIN BOARD, COMPLETE (CX5iP: MX)
********************
< CAPACITOR >
C110 1-164-856-81 CERAMIC CHIP 18PF 5% 50V
C111 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C162 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C198 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C199 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C301 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
MAINFL IP
