Sony HCD-CX4iP - Page 54

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-CX4iP/CX5iP
54
R1169 1-218-929-11 METAL CHIP 10 5% 1/16W
R1221 1-218-990-81 SHORT CHIP 0
R1222 1-218-990-81 SHORT CHIP 0
R1223 1-218-990-81 SHORT CHIP 0
R1224 1-218-990-81 SHORT CHIP 0
R1236 1-218-990-81 SHORT CHIP 0
R1241 1-218-990-81 SHORT CHIP 0
R1265 1-218-965-11 METAL CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB525 1-234-378-21 RES, NETWORK 10K (1005X4)
RB549 1-234-378-21 RES, NETWORK 10K (1005X4)
< VIBRATOR >
X110 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X113 1-813-005-21 VIBRATOR, CERAMIC (5MHz)
X501 1-814-450-11 QUARTZ CRYSTAL UNITS (16.9344MHz)
X601 1-814-267-11 QUARTZ CRYSTAL UNIT (24.576MHz)
************************************************************
POWER-KEY BOARD
****************
< CONNECTOR >
CN695 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
< LED >
D695 6-501-483-01 LED SLR-325VCT31P (STANDBY)
< RESISTOR >
R695 1-216-820-11 METAL CHIP 820 5% 1/10W
< SWITCH >
S695 1-762-875-21 SWITCH, KEYBOARD (I/
1
)
************************************************************
RMC BOARD
**********
< CAPACITOR >
C692 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< IC >
IC691 6-600-767-01 IC PNA4823M02S0
< RESISTOR >
R691 1-216-805-11 METAL CHIP 47 5% 1/10W
R692 1-216-837-11 METAL CHIP 22K 5% 1/10W
R693 1-216-864-11 SHORT CHIP 0
************************************************************
SP BOARD
*********
< CONNECTOR >
CN1701 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
< COIL >
L1701 1-457-077-11 AIR-CORE COIL
L1702 1-457-078-11 AIR-CORE COIL
L1801 1-457-077-11 AIR-CORE COIL
L1802 1-457-078-11 AIR-CORE COIL
< TERMINAL >
TB1701 1-780-639-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKERS L/R)
************************************************************
A-1816-190-A TUNER BOARD, COMPLETE
**********************
< CAPACITOR >
C901 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C902 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C903 1-107-820-81 CERAMIC CHIP 0.1uF 16V
C907 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C908 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C909 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C910 1-164-936-11 CERAMIC CHIP 680PF 10% 50V
C911 1-164-936-11 CERAMIC CHIP 680PF 10% 50V
C912 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C913 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN901 1-842-440-11 HEADER (2.5 mm) 3P (ANTENNA FM)
CN902 1-794-627-51 CONNECTOR, FFC/FPC 7P
CN903 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D901 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
ET901 1-780-482-11 EARTH TERMINAL
< FILTER >
FL901 1-236-711-21 FILTER, BAND PASS
< IC >
IC901 6-716-363-01 IC RS5B700-0002E2
< COIL >
L902 1-481-813-21 INDUCTOR 1uH
L903 1-412-973-11 INDUCTOR 0.33uH
< RESISTOR >
R901 1-218-990-81 SHORT CHIP 0
R902 1-216-797-11 METAL CHIP 10 5% 1/10W
R903 1-218-929-11 METAL CHIP 10 5% 1/16W
R904 1-216-864-11 SHORT CHIP 0
R906 1-216-864-11 SHORT CHIP 0
R907 1-216-809-11 METAL CHIP 100 5% 1/10W
R908 1-218-929-11 METAL CHIP 10 5% 1/16W
R910 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R913 1-216-864-11 SHORT CHIP 0
R918 1-216-295-91 SHORT CHIP 0
R919 1-216-864-11 SHORT CHIP 0
R921 1-216-295-91 SHORT CHIP 0
RMC TUNERSPMAIN POWER-KEY
