LOCATION OF PARTS AND CONTROLS
1 1/u (Power) button and indicator
2 DEMO (STANDBY) button (DR7AV)
POWER SAVE/DEMO (STANDBY)
button (XB800AV)
3 DISPLAY button
4 SPECTRUM ANALYZER button
5 Display window
6 GEQ control button
7 SYNC BASS button
8 SYNC EQ button
9 Remote sensor
10 PTY button (XB800AV)
11 TUNING MODE button
12 STEREO/MONO button
13 ENTER/NEXT button and indicator
14 TUNER MEMORY button
15 TUNER/BAND button
16 TUNING - button
17 TUNING + button
18 FUNCTION button
19 VOLUME knob
20 PHONES jack
21 MIC LEVEL knob
22 MIX MIC jack
23 GROOVE button and indicator
24 SUPER WOOFER button and indicator
25 MODE button
26 ª (B Deck) button and indicator
27 · (B Deck) button and indicator
28 p (B Deck) button
29 0 (B Deck) button
30 ) (B Deck) button
31 P (B Deck) button
32 r REC (B Deck) button
33 HI-SPEED DUB button
34 CD SYNCHRO button
35 PLAY MODE button
36 REPEAT button
37 0 (CD) button
38 ) (CD) button
39 ·P (CD) button and indicator
40 p (CD) button
41 DISK SKIP button
42 = AMS + knob
43 VIDEO2 INPUT jacks
44 PRO LOGIC button and indicator
45 EDIT button
46 NON-STOP button and indicator
47 LOOP button
48 FLASH button
49 DISC 5 button
50 DISC 4 button
51 DISC 3 button
52 DISC 2 button
53 DISC 1 button
54 DOLBY NR button
55 DIRECTION button
56 ) (A Deck) button
57 0 (A Deck) button
58 p (A Deck) button
59 · (A Deck) button
60 ª (A Deck) button
61 KARAOKE PON/MPX button
62 DSP button and indicator
63 EFFECT button and indicator
64 ENTER button and indicator
65 GEQ CONTROL button
66 P. FILE MEMORY
67 Equalizer indicators
68 t/CLOCK SET button
69 SLEEP button
70 REC button and indicator
71 DAILY button and indicator
• AMS is the abbreviation for Automatic
Music Sensor.
