Sony HCD-EC50 - CD Section and Base Unit BU-K6 BD83 S-WOD) Section

10
HCD-EC50
3-8. CD SECTION AND BASE UNIT (BU-K6BD83S-WOD) SECTION
2 four screws
(BV3 × 10 )
7 CD section and base unit
(BU-K6BD83S-WOD) section
6 tray panel
4 wire (flat type)
23core
5 wire (flat type)
13core
3 Remove the CD section and base unit
(BU-K6BD83S-WOD) section in the
direction of the arrow.
1 wire (flat type)
23core (CNS104)
