Sony HCD-EC50 - Chassis (Main Mold); PT Board and Power Transformer

11
HCD-EC50
3-9. CHASSIS (MAIN MOLD)
1 eight screws
(BV3 × 10 )
2 rear cabint
4 six screws
(BVTP4 × 12 )
3 Remove soldering from
the two points
8 chassis (main mold)
6 HOLD board
5 screw
(BV3 × 10 )
7 AC cord
3-10. PT BOARD AND POWER TRANSFORMER
1 four screws
(BV4 × 8 )
2 PT board,
power transformer
