51
HCD-EC50
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R733 1-216-841-11 METAL CHIP 47K 5% 1/10W
R734 1-216-817-11 METAL CHIP 470 5% 1/10W
R735 1-216-821-11 METAL CHIP 1K 5% 1/10W
R736 1-216-833-11 METAL CHIP 10K 5% 1/10W
R738 1-216-833-11 METAL CHIP 10K 5% 1/10W
R739 1-216-833-11 METAL CHIP 10K 5% 1/10W
R742 1-216-821-11 METAL CHIP 1K 5% 1/10W
R743 1-216-821-11 METAL CHIP 1K 5% 1/10W
R744 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R745 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R746 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R747 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R748 1-216-841-11 METAL CHIP 47K 5% 1/10W
R749 1-216-821-11 METAL CHIP 1K 5% 1/10W
R750 1-216-821-11 METAL CHIP 1K 5% 1/10W
R751 1-216-845-11 METAL CHIP 100K 5% 1/10W
R753 1-216-809-11 METAL CHIP 100 5% 1/10W
R754 1-216-833-11 METAL CHIP 10K 5% 1/10W
R755 1-216-864-11 SHORT CHIP 0
R756 1-216-821-11 METAL CHIP 1K 5% 1/10W
R757 1-216-845-11 METAL CHIP 100K 5% 1/10W
R758 1-216-821-11 METAL CHIP 1K 5% 1/10W
R759 1-216-809-11 METAL CHIP 100 5% 1/10W
R760 1-216-845-11 METAL CHIP 100K 5% 1/10W
R761 1-216-841-11 METAL CHIP 47K 5% 1/10W
R762 1-216-833-11 METAL CHIP 10K 5% 1/10W
R763 1-216-837-11 METAL CHIP 22K 5% 1/10W
R764 1-216-837-11 METAL CHIP 22K 5% 1/10W
R765 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R766 1-216-837-11 METAL CHIP 22K 5% 1/10W
R767 1-216-849-11 METAL CHIP 220K 5% 1/10W
R768 1-216-833-11 METAL CHIP 10K 5% 1/10W
R769 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R770 1-216-841-11 METAL CHIP 47K 5% 1/10W
R771 1-216-821-11 METAL CHIP 1K 5% 1/10W
R772 1-216-817-11 METAL CHIP 470 5% 1/10W
R773 1-216-833-11 METAL CHIP 10K 5% 1/10W
R774 1-216-837-11 METAL CHIP 22K 5% 1/10W
R775 1-216-841-11 METAL CHIP 47K 5% 1/10W
R776 1-216-821-11 METAL CHIP 1K 5% 1/10W
R777 1-216-817-11 METAL CHIP 470 5% 1/10W
R778 1-216-821-11 METAL CHIP 1K 5% 1/10W
R779 1-216-809-11 METAL CHIP 100 5% 1/10W
R780 1-216-841-11 METAL CHIP 47K 5% 1/10W
R781 1-216-833-11 METAL CHIP 10K 5% 1/10W
R784 1-216-845-11 METAL CHIP 100K 5% 1/10W
R785 1-216-833-11 METAL CHIP 10K 5% 1/10W
R786 1-216-797-11 METAL CHIP 10 5% 1/10W
R787 1-216-805-11 METAL CHIP 47 5% 1/10W
R788 1-216-864-11 SHORT CHIP 0
< SWITCH >
SW700 1-786-417-11 SW, RTRY RE012307PVB30F (VOLUME)
SW701 1-762-875-21 SWITCH, KEYBOARD (?/1)
SW702 1-762-875-21 SWITCH, KEYBOARD (DSGX)
SW703 1-762-875-21 SWITCH, KEYBOARD ( –)
SW704 1-762-875-21 SWITCH, KEYBOARD ( +)
SW705 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
SW706 1-762-875-21 SWITCH, KEYBOARD (EQ)
SW708 1-762-875-21 SWITCH, KEYBOARD (Z)
SW709 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
SW710 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
SW711 1-762-875-21 SWITCH, KEYBOARD (STOP x)
SW712 1-762-875-21 SWITCH, KEYBOARD (TUNING –/l/m)
SW713 1-762-875-21 SWITCH, KEYBOARD (TUNING +/L/M)
SW714 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
SW715 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
SW716 1-762-875-21 SWITCH, KEYBOARD (CD u)
SW719 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
SW720 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
SW721 1-762-875-21 SWITCH, KEYBOARD
(PLAY MODE/TUNING MODE)
< VIBRATOR >
X701 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X702 1-795-054-51 VIBRATOR, CERAMIC (4.19MHz)
************************************************************
A-1144-825-A PT BOARD, COMPLETE
******************
< CAPACITOR >
C051 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C052 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C053 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C054 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C055 1-100-385-91 CERAMIC CHIP 0.47uF 25V
< DIODE >
D051 8-719-000-07 DIODE MC2836
D052 6-500-335-01 DIODE MC2838-T112-1
< COIL >
0L001 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSFORMER >
0PT002 1-443-846-11 TRANSFORMER, POWER
< RESISTOR >
R051 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R052 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
0RY001 1-755-334-11 RELAY, AC POWER
************************************************************
A-1146-444-A TRANSISTOR BOARD, COMPLETE
***************************
< CAPACITOR >
C118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C119 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< IC >
IC101 8-759-701-59 IC NJM78M09FA
PTPANEL TRANSISTOR
