18
HCD-EC50
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C835 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C836 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C838 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C839 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C840 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C841 1-126-965-91 ELECT 22uF 20% 50V
C843 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(US, CND)
C847 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT US, CND)
C847 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(US, CND)
C848 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT US, CND)
C848 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(US, CND)
C851 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C852 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C853 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C854 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C855 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C856 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C873 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
(EXCEPT US, CND)
< FILTER >
CF801 1-795-426-11 FILTER, CERAMIC (EXCEPT US, CND)
CF802 1-579-554-21 FILTER, CERAMIC
CF803 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
∗ CN102 1-564-187-00 PIN, CONNECTOR (AEP, UK, CET, KR)
CNP151 1-819-136-11 PIN, CONNECTOR 8P
CNP201 1-819-133-11 PIN, CONNECTOR
CNP202 1-815-446-11 PIN, CONNECTOR (PWB) 5P
CNP501 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CNP502 1-815-444-11 PIN, CONNECTOR (PWB) 3P
∗ CNP802 1-506-680-11 PLUG, CONNECTOR (2.5MM) 3P (ANTENNA)
CNS104 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CNS111 1-779-295-11 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
< DIODE >
D107 6-501-046-01 DIODE 1N5402-F46
D108 6-501-046-01 DIODE 1N5402-F46
D109 6-501-046-01 DIODE 1N5402-F46
D110 6-501-046-01 DIODE 1N5402-F46
D111 6-500-522-31 DIODE 10EDB40-TB5
D113 6-500-522-31 DIODE 10EDB40-TB5
D131 6-500-522-31 DIODE 10EDB40-TB5
D132 8-719-000-07 DIODE MC2836
D154 6-500-335-01 DIODE MC2838-T112-1
D156 8-719-000-07 DIODE MC2836
D191 6-500-522-31 DIODE 10EDB40-TB5
D192 6-500-522-31 DIODE 10EDB40-TB5
D193 6-501-164-01 DIODE UDZW-TE17-3.9B
D802 6-501-369-01 DIODE SV230-TB-E
D803 6-501-369-01 DIODE SV230-TB-E
D812 8-719-062-51 DIODE 1PS226-115
D813 8-719-062-51 DIODE 1PS226-115
D814 8-719-062-51 DIODE 1PS226-115
D851 6-501-142-01 DIODE SVC347A-TL-E
D901 6-500-335-01 DIODE MC2838-T112-1 (E3, SP, KR, AUS)
< EARTH TERMINAL >
EP102 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC401 6-702-895-01 IC BD3881FV
IC801 6-708-840-01 IC LV23003VA
< JACK >
J101 1-536-708-81 TERMINAL BOARD, PUSH (4P) (SPEAKER)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR102 1-216-864-11 SHORT CHIP 0
JR103 1-216-864-11 SHORT CHIP 0
JR104 1-216-864-11 SHORT CHIP 0
JR105 1-216-864-11 SHORT CHIP 0
JR106 1-216-864-11 SHORT CHIP 0 (E3, SP, KR, AUS)
JR107 1-216-864-11 SHORT CHIP 0 (E3, SP, KR, AUS)
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR803 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-456-107-11 COIL, AIR-CORE
L102 1-456-107-11 COIL, AIR-CORE
L501 1-456-094-11 TRANSFORMER, BIAS OSCILLATION
L803 1-433-741-11 TRANSFORMER, IF
L804 1-457-163-11 COIL, AIR-CORE
L805 1-457-162-11 COIL, AIR-CORE
L806 1-457-168-11 COIL, DET
L851 1-457-161-11 COIL, AM ANTENNA
L852 1-456-596-11 COIL, MW OSC
< TRANSISTOR >
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q121 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q122 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q131 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q132 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q133 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q134 1-801-806-11 TR DTC144EKA
Q135 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q137 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q138 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q151 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q152 8-729-600-22 TRANSISTOR 2SA1235-F
Q153 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q154 8-729-600-22 TRANSISTOR 2SA1235-F
Q191 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q192 8-729-036-86 TRANSISTOR KTC3203Y-AT
MAIN
Ver. 1.3
