Sony HCD-EX770 - Page 43

– 25 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C142 1-128-576-11 ELECT 100uF 20% 63V
C145 1-126-967-11 ELECT 47uF 20% 50V
C146 1-164-159-11 CERAMIC 0.1uF 50V
C161 1-128-563-11 ELECT 100uF 20% 100V
C162 1-128-563-11 ELECT 100uF 20% 100V
C163 1-126-941-11 ELECT 470uF 20% 25V
C164 1-126-941-11 ELECT 470uF 20% 25V
C171 1-126-964-11 ELECT 10uF 20% 50V
C181 1-125-705-11 CAPACITOR 0.22F 5.5V
C191 1-126-964-11 ELECT 10uF 20% 50V
C201 1-126-933-11 ELECT 100uF 20% 10V
C202 1-136-177-00 FILM 1uF 5% 50V
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-102-953-00 CERAMIC 18PF 5% 50V
C205 1-164-056-11 CERAMIC 27PF 5% 50V
C206 1-164-159-11 CERAMIC 0.1uF 50V
C207 1-162-282-31 CERAMIC 100PF 10% 50V
C208 1-162-294-31 CERAMIC 0.001uF 10% 50V
C209 1-164-159-11 CERAMIC 0.1uF 50V
C210 1-164-159-11 CERAMIC 0.1uF 50V
C211 1-164-159-11 CERAMIC 0.1uF 50V
C212 1-164-159-11 CERAMIC 0.1uF 50V
C213 1-162-306-11 CERAMIC 0.01uF 20% 16V
C214 1-162-306-11 CERAMIC 0.01uF 20% 16V
C215 1-162-282-31 CERAMIC 100PF 10% 50V
C216 1-162-282-31 CERAMIC 100PF 10% 50V
C217 1-162-282-31 CERAMIC 100PF 10% 50V
C218 1-162-282-31 CERAMIC 100PF 10% 50V
C219 1-162-282-31 CERAMIC 100PF 10% 50V
C220 1-162-282-31 CERAMIC 100PF 10% 50V
C221 1-162-282-31 CERAMIC 100PF 10% 50V
C271 1-126-960-11 ELECT 1uF 20% 50V
C272 1-164-159-11 CERAMIC 0.1uF 50V
C281 1-162-282-31 CERAMIC 100PF 10% 50V
C301 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C302 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP, UK)
C303 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C304 1-126-964-11 ELECT 10uF 20% 50V
(AEP, UK)
C305 1-126-967-11 ELECT 47uF 20% 16V
(AEP, UK)
C306 1-136-177-00 FILM 1uF 5% 50V
(AEP, UK)
C307 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C308 1-126-967-11 ELECT 47uF 20% 16V
(AEP, UK)
C309 1-136-177-00 FILM 1uF 5% 50V
(AEP, UK)
C310 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
C311 1-126-961-11 ELECT 2.2uF 20% 50V
(AEP, UK)
C312 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP, UK)
C313 1-101-884-00 CERAMIC 56PF 5% 50V
(AEP, UK)
C314 1-101-884-00 CERAMIC 56PF 5% 50V
(AEP, UK)
C315 1-126-967-11 ELECT 47uF 20% 16V
(AEP, UK)
C316 1-164-159-11 CERAMIC 0.1uF 50V
(AEP, UK)
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC (HK, SP)
CF1 1-579-374-71 FILTER, CERAMIC (AEP, UK)
CF2 1-760-393-11 FILTER, CERAMIC (AEP, UK)
CF3 1-567-389-11 FILTER, CERAMIC (HK, SP)
CF3 1-760-393-11 FILTER, CERAMIC (AEP, UK)
CF4 1-527-981-00 FILTER, CERAMIC
CF5 1-577-075-11 OSCILLATOR, CERAMIC
CF6 1-760-220-11 FILTER, CERAMIC
< CONNECTOR >
CN101 1-770-158-21 HOUSING, CONNECTOR 7P
(SYSTEM CONTROL)
CN102 1-695-342-31 PIN, CONNECTOR (PC BOARD) 19P
* CN281 1-565-561-11 PIN, CONNECTOR 3P (AU BUS)
< DIODE >
D1 8-719-987-63 DIODE 1N4148M
D2 8-719-987-63 DIODE 1N4148M
D102 8-719-987-63 DIODE 1N4148M (AEP, UK)
D103 8-719-987-63 DIODE 1N4148M
D104 8-719-987-63 DIODE 1N4148M
D105 8-719-987-63 DIODE 1N4148M
D111 8-719-200-82 DIODE 11ES2
D112 8-719-200-82 DIODE 11ES2
D113 8-719-200-82 DIODE 11ES2
D121 8-719-200-82 DIODE 11ES2
D122 8-719-200-82 DIODE 11ES2
D123 8-719-200-82 DIODE 11ES2
D124 8-719-200-82 DIODE 11ES2
D125 8-719-001-42 DIODE UZL-11M1
D126 8-719-200-82 DIODE 11ES2
D127 8-719-200-82 DIODE 11ES2
D141 8-719-200-82 DIODE 11ES2
D142 8-719-200-82 DIODE 11ES2
D143 8-719-934-23 DIODE HZS30-3L
D161 8-719-014-48 DIODE UZP-4.7B
D191 8-719-933-33 DIODE HZS6A1L
D271 8-719-987-63 DIODE 1N4148M
D281 8-719-987-63 DIODE 1N4148M
D282 8-719-987-63 DIODE 1N4148M
< GROUND TERMINAL >
E101 1-537-770-21 TERMINAL BOARD, GROUND
E103 1-537-770-21 TERMINAL BOARD, GROUND (AEP, UK)
< FRONTEND >
FE1 1-233-532-11 ENCAPSULATED COMPONENT (HK, SP)
FE1 1-233-542-11 ENCAPSULATED COMPONENT (AEP, UK)
FE2 1-233-514-11 ENCAPSULATED COMPONENT (AEP, UK)
FE2 1-239-634-11 ENCAPSULATED COMPONENT, AM.RF
(HK, SP)
MAIN
