Sony HCD-EX770 - 6-2. BLOCK DIAGRAM (2;2)

– 22 –
• Waveforms
– BD Section –
1 IC101 #¡ (RFO) (PLAY Mode)
500 mV/DIV, 500 ns/DIV 6 IC103 @∞ (XPCK)
– MAIN/PANEL/MOTOR Section –
1 IC501 !¡ (X2)
3 Vp-p
10 MHz
5.3 Vp-p
14 ns
2 IC101 $¢ (TEI) (PLAY Mode)
50 mV/DIV, 1 µs/DIV
7 IC103 @™ (BCLK)
5 Vp-p
474 ns
3 IC101 2 (FEI) (PLAY Mode)
50 mV/DIV, 1 µs/DIV
8 IC103 @º (LRCK)
5.1 Vp-p
22.8 µ s
4 IC103 3 (MDP) (PLAY Mode)
9 IC104 6 (XTO)
4.6 Vp-p
16.9344 MHz
5 IC103 @• (RFCK)
Approx. 150 mVp-p
Approx. 100 mVp-p
2.6 Vp-p
7.6 µ s
5.1 Vp-p
136 µ s
1.3 ± 0.3 Vp-p
