111
HCD-FLX5D/FLX7D
Pin No. Pin Name I/O Description
112
A0 O
Address signal output to the S-RAM
113
PM I
PLL reset signal input from the digital audio interface receiver
114
SDI3 I
Audio serial data input from the digital audio processor (FLX7D only)
115
SDI4 I
Audio serial data input from the digital audio processor (FLX7D only)
116
SYNC I
Synchronous/asychronous selection signal input terminal
“L”: Synchronous, “H”: asynchronous (fixed at “H” in this set)
117 TST2 —
Ground terminal
118 GP11 —
Not used
119 TST3 —
Ground terminal
120
VDDI —
Power supply terminal (+3.3V)
