Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
133
HCD-FLX5D/FXL7D
CD MOTOR CENTER SW AMP CLAMP MOTOR
< RESISTOR >
R315 1-216-805-11 METAL CHIP 47 5% 1/10W
R316 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R340 1-216-834-11 METAL CHIP 12K 5% 1/10W
************************************************************
A-1058-400-A CENTER SW AMP BOARD, COMPLETE
(EXCEPT FLX5D: KR, TH)
A-1058-666-A CENTER SW AMP BOARD, COMPLETE
(FLX5D: TH)
A-1058-700-A CENTER SW AMP BOARD, COMPLETE
(FLX5D: KR)
*******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-126-965-11 ELECT 22uF 20% 50V
C505 1-136-497-81 FILM 0.1uF 5% 50V
C506 1-136-497-81 FILM 0.1uF 5% 50V
C507 1-128-560-11 ELECT 22uF 20% 100V
C508 1-128-560-11 ELECT 22uF 20% 100V
C520 1-162-294-31 CERAMIC 0.001uF 10% 50V
C521 1-128-562-11 ELECT 47uF 20% 100V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 25V
C555 1-136-497-81 FILM 0.1uF 5% 50V
C556 1-136-497-81 FILM 0.1uF 5% 50V
C591 1-130-777-00 MYLAR 0.1uF 5% 100V
C592 1-130-777-00 MYLAR 0.1uF 5% 100V
C593 1-135-632-51 ELECT 2200uF 20% 63V
C594 1-135-632-51 ELECT 2200uF 20% 63V
C921 1-130-483-00 MYLAR 0.01uF 5% 50V
C922 1-130-483-00 MYLAR 0.01uF 5% 50V
C923 1-126-955-11 ELECT 4700uF 20% 35V
C925 1-126-964-11 ELECT 10uF 20% 50V
C926 1-126-767-11 ELECT 1000uF 20% 16V
C927 1-126-964-11 ELECT 10uF 20% 50V
C928 1-126-926-11 ELECT 1000uF 20% 10V
< CONNECTOR >
CN502 1-573-826-11 CONNECTOR, BOARD TO BOARD 12P
CN503 1-573-827-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D551 8-719-991-33 DIODE 1SS133T-77
D552 8-719-991-33 DIODE 1SS133T-77
D591 6-500-249-01 DIODE D15XB20
D921 8-719-028-23 DIODE D3SBA20-4101
< IC >
IC501 8-749-017-16 IC STK442-130M
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q521 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q522 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q922 8-729-116-02 TRANSISTOR BA1A4M-TP
Q923 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R501 1-247-831-91 CARBON 1K 5% 1/4W
R502 1-247-871-91 CARBON 47K 5% 1/4W
R503 1-249-414-11 CARBON 560 5% 1/4W
R504 1-247-871-91 CARBON 47K 5% 1/4W
0R505 1-217-156-00 METAL 0.22 10% 5W F
0R505 1-245-233-11 METAL 0.22 10% 5W F
0R506 1-217-156-00 METAL 0.22 10% 5W F
0R506 1-245-233-11 METAL 0.22 10% 5W F
R507 1-247-831-91 CARBON 1K 5% 1/4W
R508 1-249-431-11 CARBON 15K 5% 1/4W
R510 1-249-393-11 CARBON 10 5% 1/4W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R512 1-212-881-11 FUSIBLE 100 5% 1/4W F
R519 1-247-863-11 CARBON 22K 5% 1/4W
0R520 1-202-972-61 FUSIBLE 1 5% 1/4W F
R521 1-249-421-11 CARBON 2.2K 5% 1/4W
R522 1-247-863-11 CARBON 22K 5% 1/4W
R523 1-249-439-11 CARBON 68K 5% 1/4W
R524 1-249-426-11 CARBON 5.6K 5% 1/4W
R525 1-249-421-11 CARBON 2.2K 5% 1/4W
R526 1-249-421-11 CARBON 2.2K 5% 1/4W
R551 1-247-831-91 CARBON 1K 5% 1/4W
R552 1-247-871-91 CARBON 47K 5% 1/4W
R553 1-249-415-11 CARBON 680 5% 1/4W
R554 1-247-871-91 CARBON 47K 5% 1/4W
0R555 1-245-233-11 METAL 0.22 10% 5W F
0R556 1-245-233-11 METAL 0.22 10% 5W F
R557 1-247-831-91 CARBON 1K 5% 1/4W
R558 1-249-431-11 CARBON 15K 5% 1/4W
R560 1-249-393-11 CARBON 10 5% 1/4W
R591 1-247-879-91 CARBON 100K 5% 1/4W
R592 1-247-879-91 CARBON 100K 5% 1/4W
R921 1-247-807-31 CARBON 100 5% 1/4W
R922 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
1-683-901-11 CLAMP MOTOR BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C711 1-162-306-11 CERAMIC 0.01uF 20% 16V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
