Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
139
HCD-FLX5D/FXL7D
FRONT REAR AMP GC
R481 1-247-831-91 CARBON 1K 5% 1/4W
R482 1-247-871-91 CARBON 47K 5% 1/4W
R483 1-249-415-11 CARBON 680 5% 1/4W
R484 1-247-871-91 CARBON 47K 5% 1/4W
0R485 1-208-602-11 METAL 0.22 2W F
0R486 1-208-602-11 METAL 0.22 2W F
R487 1-247-831-91 CARBON 1K 5% 1/4W
R488 1-247-863-11 CARBON 22K 5% 1/4W
R490 1-249-393-11 CARBON 10 5% 1/4W
< THERMISTOR >
TH401 1-807-796-11 THERMISTOR
************************************************************
A-4750-816-A GC BOARD, COMPLETE (EXCEPT FLX5D: TH)
A-4753-591-A GC BOARD, COMPLETE (FLX5D: TH)
*******************
4-238-986-01 HOLDER (FL)
< CAPACITOR >
C201 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C202 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C203 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C204 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C205 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C206 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C207 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C208 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C212 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C243 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C250 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C260 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C261 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C262 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C277 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C281 1-126-916-11 ELECT 1000uF 20% 6.3V
C282 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C285 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C286 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C287 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C288 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C289 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C290 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C291 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C292 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C293 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C294 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C295 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C296 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C297 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C298 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C299 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C300 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN201 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P
* CN202 1-568-862-11 S0CKET, CONNECTOR 19P
CN203 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN204 1-568-860-11 SOCKET, CONNECTOR 17P
CN206 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN207 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE) 5P
CN208 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-069-29 DIODE RB520S-30TE61
D203 6-500-522-31 DIODE 10EDB40-TB5
D204 8-719-988-61 DIODE 1SS355TE-17
< EARTH TERMINAL >
* EP201 1-537-738-21 TERMINAL, EARTH
* EP202 1-537-738-21 TERMINAL, EARTH
< SHORT >
FB201 1-216-864-11 SHORT CHIP 0
FB202 1-216-864-11 SHORT CHIP 0
FB284 1-216-864-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
FL201 1-518-975-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 6-803-945-01 IC MB90M407PF-G-138-BNDE1
IC202 6-703-679-11 IC PT8300R-TP
< SHORT >
JR201 1-216-864-11 SHORT CHIP 0
JR202 1-216-864-11 SHORT CHIP 0
JR203 1-216-864-11 SHORT CHIP 0
JR204 1-216-864-11 SHORT CHIP 0
JR205 1-216-864-11 SHORT CHIP 0
JR206 1-216-864-11 SHORT CHIP 0
JR207 1-216-864-11 SHORT CHIP 0
JR208 1-216-864-11 SHORT CHIP 0
JR209 1-216-864-11 SHORT CHIP 0
JR211 1-216-864-11 SHORT CHIP 0
JR212 1-216-864-11 SHORT CHIP 0
JR213 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q201 8-729-029-94 TRANSISTOR DTC143TSA
Q202 8-729-029-94 TRANSISTOR DTC143TSA
Q203 8-729-119-78 TRANSISTOR 2SC2785-HFE
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
