Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
156
HCD-FLX5D/FXL7D
SUB TRANS TC DOOR TC DOOR SW TRANS VIDEO
1-861-346-11 TC DOOR BOARD
*************
< DIODE >
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-988-61 DIODE 1SS355TE-17
************************************************************
1-861-345-11 TC DOOR SW BOARD
****************
< SWITCH >
S325 1-771-264-11 SWITCH, PUSH (DETECTION) (1 KEY)
(CASSETTE LID OPEN/CLOSE DETECT)
************************************************************
A-4730-184-A TRANS BOARD, COMPLETE (FLX5D: TH)
A-4730-186-A TRANS BOARD, COMPLETE (FLX5D: KR)
A-4730-190-A TRANS BOARD, COMPLETE
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
A-4730-203-A TRANS BOARD, COMPLETE (FLX5D: AUS)
**********************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C913 1-128-576-11 ELECT 100uF 20% 63V
C914 1-126-960-11 ELECT 1uF 20% 50V
C915 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
* CN914 1-564-522-11 PLUG, CONNECTOR 7P
* CN915 1-564-521-11 PLUG, CONNECTOR 6P
* CN916 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D911 6-500-522-31 DIODE 10EDB40-TB5
D912 8-719-983-96 DIODE MTZJ-T-72-39A
D913 8-719-160-29 DIODE RD6.2FB2
D914 8-719-109-68 DIODE RD3.6ESB1
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP)
< RESISTOR >
0R913 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
R914 1-247-831-91 CARBON 1K 5% 1/4W
R915 1-249-429-11 CARBON 10K 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R917 1-247-807-31 CARBON 100 5% 1/4W
************************************************************
1-684-692-11 VIDEO BOARD
***********
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20% 25V
C702 1-164-159-11 CERAMIC 0.1uF 50V
C703 1-126-965-11 ELECT 22uF 20% 50V
C704 1-164-159-11 CERAMIC 0.1uF 50V
C741 1-164-159-11 CERAMIC 0.1uF 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
A-4730-194-A SUB TRANS BOARD, COMPLETE (FLX5D: KR)
A-4730-199-A SUB TRANS BOARD, COMPLETE
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
A-4730-206-A SUB TRANS BOARD, COMPLETE (FLX5D: AUS)
A-4730-220-A SUB TRANS BOARD, COMPLETE (FLX5D: TH)
**************************
1-533-217-41 HOLDER, FUSE
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
< CAPACITOR >
C901 1-104-665-11 ELECT 100uF 20% 25V
C902 1-126-935-11 ELECT 470uF 20% 16V
C903 1-164-159-11 CERAMIC 0.1uF 50V
C905 1-126-964-11 ELECT 10uF 20% 50V
C906 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
(FLX5D: KR, TH, AUS)
CN902 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
CN903 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
< DIODE >
D901 6-500-522-31 DIODE 10EDB40-TB5
D902 6-500-522-31 DIODE 10EDB40-TB5
D903 6-500-522-31 DIODE 10EDB40-TB5
D904 6-500-522-31 DIODE 10EDB40-TB5
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-991-33 DIODE 1SS133T-77
< IC >
IC901 8-759-647-10 IC uPC2933HF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-467-21 RELAY (POWER)
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(FLX5D: E2, E3, E15, EA, SP, MY, PH/FLX7D)
< TRANSFORMER >
0T901 1-437-677-11 TRANSFORMER, POWER
************************************************************
