3-5. PRINTED WIRING BOARD — DMB08 BOARD (SIDE A) —
• See page 7 for Circuit Boards Location. :Uses unleaded solder.
IC401
IC301
IC901
IC813
IC612
IC605
IC606
IC801
IC607
IC701
IC206
IC402
D
DDCON
BOARD
CN800
(Page 34)
FOR
CHECK
FOR
CHECK
A
RF
BOARD
CN002
(Page 9)
F
IO
BOARD
CN201
(Page 31)
E
IO
BOARD
CN601
(Page 31)
SWITCHING
REGULATOR
CN8
C
AMP
BOARD
CN301
(Page 26)
B
AMP
BOARD
CN302
(Page 26)
G
RELAY
BOARD
CN701
(Page 11)
12
A
B
C
D
E
F
3456789
CN006
1
2
27
28
R071
C009
C002
C012
RB901
R094
R092
R953
R983
Q914
E
R894
C908
RB902
C921
C606
14
• Semiconductor
Location
Ref. No. Location
D900 C-2
D901 C-4
IC206 D-5
IC301 C-2
IC401 D-2
IC402 D-2
IC605 C-8
IC606 C-7
IC607 B-7
IC612 B-6
IC701 D-4
IC801 B-5
IC813 C-4
IC901 B-2
Q914 C-3
