56
HCD-FR1/FR8/FR9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL KEY DDCON
< RESISTOR >
R860 1-216-864-11 SHORT CHIP 0
R861 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R866 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R867 1-216-864-11 SHORT CHIP 0
R868 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R874 1-216-833-11 METAL CHIP 10K 5% 1/10W
R875 1-216-837-11 METAL CHIP 22K 5% 1/10W
R876 1-216-841-11 METAL CHIP 47K 5% 1/10W
< SWITCH >
✩ S801 1-771-884-31 SWITCH, TACTILE (FUNCTION)
✩ S807 1-771-884-31 SWITCH, TACTILE (HX)
✩ S808 1-771-884-31 SWITCH, TACTILE (.)
✩ S809 1-771-884-31 SWITCH, TACTILE (+ (VOLUME))
✩ S815 1-771-884-31 SWITCH, TACTILE (x)
✩ S816 1-771-884-31 SWITCH, TACTILE (>)
✩ S817 1-771-884-31 SWITCH, TACTILE (– (VOLUME))
✩ S818 1-771-884-31 SWITCH, TACTILE (A)
************************************************************
A-4751-769-A DDCON BOARD, COMPLETE
**********************
< CAPACITOR >
C817 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C818 1-124-584-00 ELECT 100uF 20% 10V
C819 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C820 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C822 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C824 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C825 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C826 1-124-234-00 ELECT 22uF 20% 10V
C827 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C828 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C829 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C830 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C831 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C832 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C833 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C834 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C835 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C836 1-126-795-11 ELECT 10uF 20% 50V
C837 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN800 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN801 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN802 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D810 8-719-988-61 DIODE 1SS355TE-17
D811 8-719-988-61 DIODE 1SS355TE-17
D813 8-719-988-61 DIODE 1SS355TE-17
D814 8-719-988-61 DIODE 1SS355TE-17
D815 8-719-069-56 DIODE UDZSTE-176.2B
< FERRITE BEAD >
FB001 1-469-324-21 FERRITE, EMI (SMD)(2012)
FB002 1-469-324-21 FERRITE, EMI (SMD)(2012)
FB003 1-469-324-21 FERRITE, EMI (SMD)(2012)
FB806 1-414-813-11 FERRITE, EMI (SMD)(2012)
FB808 1-414-813-11 FERRITE, EMI (SMD)(2012)
< IC >
IC802 8-759-366-45 IC NJU3713G (TE2)
< COIL >
L804 1-410-671-31 INDUCTOR 47uH
L805 1-400-135-11 INDUCTOR 1uH
L806 1-400-135-11 INDUCTOR 1uH
L807 1-400-135-11 INDUCTOR 1uH
< TRANSISTOR >
Q802 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R806 1-216-864-11 SHORT CHIP 0
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-864-11 SHORT CHIP 0
R817 1-216-809-11 METAL CHIP 100 5% 1/10W
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-809-11 METAL CHIP 100 5% 1/10W
R823 1-216-841-11 METAL CHIP 47K 5% 1/10W
R826 1-216-820-11 METAL CHIP 820 5% 1/10W
R827 1-216-820-11 METAL CHIP 820 5% 1/10W
R829 1-216-820-11 METAL CHIP 820 5% 1/10W
R830 1-216-820-11 METAL CHIP 820 5% 1/10W
R831 1-216-820-11 METAL CHIP 820 5% 1/10W
R833 1-216-820-11 METAL CHIP 820 5% 1/10W
R834 1-216-820-11 METAL CHIP 820 5% 1/10W
R835 1-216-820-11 METAL CHIP 820 5% 1/10W
R837 1-216-820-11 METAL CHIP 820 5% 1/10W
R838 1-216-820-11 METAL CHIP 820 5% 1/10W
R839 1-216-839-11 METAL CHIP 33K 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R850 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
< TRANSFORMER >
T801 1-443-325-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
DISC KEY BOARD
**************
< CONNECTOR >
CN804 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D806 8-719-079-89 DIODE SML-020MDT-T86 (DISC 1)
D807 8-719-079-89 DIODE SML-020MDT-T86 (DISC 2)
D808 8-719-079-89 DIODE SML-020MDT-T86 (DISC 3)
D809 8-719-079-89 DIODE SML-020MDT-T86 (DISC 4)
D812 8-719-079-89 DIODE SML-020MDT-T86 (DISC 5)
DISC KEY
✩ The Part numbers of Ref.No. S801, 807-809, 815-818 are changed
with a suffix of the CONTROL KEY board. Please refer to SUPPLE-
MENT-3 of this manual at the time of replacement.
Ver. 1.7
