65
HCD-FR1/FR8/FR9
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FL HP
R980 1-218-973-11 RES-CHIP 47K 5% 1/16W
R981 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R983 1-218-973-11 RES-CHIP 47K 5% 1/16W
R984 1-218-973-11 RES-CHIP 47K 5% 1/16W
R985 1-218-985-11 RES-CHIP 470K 5% 1/16W
R986 1-218-973-11 RES-CHIP 47K 5% 1/16W
R987 1-218-973-11 RES-CHIP 47K 5% 1/16W
R989 1-218-990-11 SHORT CHIP 0
R990 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R991 1-218-965-11 RES-CHIP 10K 5% 1/16W
R992 1-218-965-11 RES-CHIP 10K 5% 1/16W
R994 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R995 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R996 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R997 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R998 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R1000 1-218-945-11 RES-CHIP 220 5% 1/16W
R1001 1-218-945-11 RES-CHIP 220 5% 1/16W
R1002 1-218-945-11 RES-CHIP 220 5% 1/16W
R1003 1-218-945-11 RES-CHIP 220 5% 1/16W
R1004 1-218-945-11 RES-CHIP 220 5% 1/16W
R1005 1-218-945-11 RES-CHIP 220 5% 1/16W
R1006 1-218-945-11 RES-CHIP 220 5% 1/16W
R1007 1-218-945-11 RES-CHIP 220 5% 1/16W
R1008 1-218-945-11 RES-CHIP 220 5% 1/16W
R1009 1-218-945-11 RES-CHIP 220 5% 1/16W
R1010 1-218-945-11 RES-CHIP 220 5% 1/16W
R1011 1-218-945-11 RES-CHIP 220 5% 1/16W
R1012 1-218-945-11 RES-CHIP 220 5% 1/16W
< NETWORK RESISTOR >
RB901 1-233-270-11 NETWORK, RES (8 GANG) 10K
RB902 1-233-270-11 NETWORK, RES (8 GANG) 10K
< VIBRATOR >
X301 1-795-375-11 VIBRATOR, CERAMIC 20MHz
X302 1-795-630-11 VIBRATOR, CRYSTAL 27MHz
X600 1-781-465-21 VIBRATOR, CRYSTAL 12.288MHz
X601 1-813-325-11 VIBRATOR, CRYSTAL 13.9MHz
X901 1-795-375-11 VIBRATOR, CERAMIC 20MHz
************************************************************
A-4751-757-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C805 1-126-795-11 ELECT 10uF 20% 50V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C841 1-117-370-11 CERAMIC CHIP 10uF 10V
C842 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C843 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C846 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C847 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C848 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C849 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C850 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
CN803 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN812 1-784-859-21 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
< FERRITE BEAD >
FB005 1-469-144-21 FERRITE, EMI (SMD)(2012)
FB807 1-414-813-11 FERRITE, EMI (SMD)(2012)
< FLUORESCENT INDICATOR >
FL801 1-519-759-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-826-33 IC NJL73H400A (
)
IC803 6-705-899-01 IC ML9208-03MBZ03B
< TRANSISTOR >
Q810 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
R828 1-216-864-11 SHORT CHIP 0
R840 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R843 1-216-833-11 METAL CHIP 10K 5% 1/10W
R844 1-216-809-11 METAL CHIP 100 5% 1/10W
R849 1-216-833-11 METAL CHIP 10K 5% 1/10W
R851 1-216-809-11 METAL CHIP 100 5% 1/10W
R852 1-216-805-11 METAL CHIP 47 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R879 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R880 1-216-821-11 METAL CHIP 1K 5% 1/10W
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-821-11 METAL CHIP 1K 5% 1/10W
************************************************************
HP BOARD
*********
< CAPACITOR >
C800 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C804 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C806 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C853 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C854 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
* CN811 1-566-002-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D800 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB800 1-500-284-21 INDUCTOR, FERRITE BEAD
FB802 1-469-144-21 FERRITE, EMI (SMD)(2012)
FB803 1-469-144-21 FERRITE, EMI (SMD)(2012)
FB805 1-469-144-21 FERRITE, EMI (SMD)(2012)
FB810 1-469-324-21 FERRITE, EMI (SMD)(2012)
< JACK >
J800 1-794-453-11 JACK (PHONES)
< COIL >
L800 1-410-387-11 INDUCTOR 33uH
L801 1-410-387-11 INDUCTOR 33uH
L802 1-469-144-21 FERRITE, EMI (SMD)(2012)
L803 1-469-144-21 FERRITE, EMI (SMD)(2012)
DMB08
Ver. 1.6
