Ref. No. Part No. Description Remark
70
HCD-FR1/FR8/FR9
1-685-006-11 STOCKER MOTOR BOARD
*********************
************************************************************
1-685-008-11 SW (1) BOARD
************
< SWITCH >
S711 1-786-382-11 SWITCH, PUSH
(1 KEY)(DISC INSERT (8/12cm))
************************************************************
1-685-009-11 SW (2) BOARD
************
< SWITCH >
S713 1-786-382-11 SWITCH, PUSH (1 KEY)(DISC IN (8/12cm))
S714 1-786-382-11 SWITCH, PUSH (1 KEY)(DISC IN (8cm))
************************************************************
1-685-010-11 SW (3) BOARD
************
< SWITCH >
S715 1-786-382-11 SWITCH, PUSH (1 KEY)(DISC OUT)
************************************************************
1-685-011-11 SW (4) BOARD
************
< SWITCH >
S716 1-786-382-11 SWITCH, PUSH (1 KEY)(STOCKER IN/OUT)
S717 1-786-382-11 SWITCH, PUSH (1 KEY)(DISC POSITION)
S718 1-786-382-11 SWITCH, PUSH (1 KEY)(STOCKING)
************************************************************
MISCELLANEOUS
**************
4 1-763-861-12 FAN, DC
0 6 1-783-531-72 CORD, POWER
8 1-828-962-11 WIRE (FLAT TYPE)(11 CORE)
62 1-829-320-11 FLEXIBLE FLAT CABLE (13 CORE)
63 1-829-321-11 FLEXIBLE FLAT CABLE (17 CORE)
106 1-829-322-11 FLEXIBLE FLAT CABLE (9 CORE)
107 1-829-319-11 FLEXIBLE FLAT CABLE (17 CORE)
108 1-828-349-11 WIRE (FLAT TYPE)(17 CORE)
109 1-829-323-11 FLEXIBLE FLAT CABLE (29 CORE)
110 1-829-326-11 FLEXIBLE FLAT CABLE (15 CORE)
111 1-829-325-11 FLEXIBLE FLAT CABLE (29 CORE)
112 1-829-324-11 FLEXIBLE FLAT CABLE (28 CORE)
113 1-500-657-11 CORE, FERRIET
0 114 1-468-838-11 REGULATOR, SWITCHING
0 603 1-477-263-11 OPTICAL PICK-UP (DBU-1)
605 1-685-250-11 FLEXIBLE BOARD
M761 A-4735-953-A MOTOR (STOCKER) ASSY (MODE)
M771 A-4735-953-A MOTOR (STOCKER) ASSY (ROLLER)
M781 A-4735-953-A MOTOR (STOCKER) ASSY (STOCKER)
S702 1-477-299-11 ENCODER, ROTARY (STOCKER POSITION)
S771 1-477-300-11 ENCODER, ROTARY (MODE)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.3
SW (1) SW (2)
STOCKER MOTOR
SW (3) SW (4)
