Sony HCD-GNX88 - Main Board Components

71
HCD-GNX88
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
Q372 8-729-802-80 TRANSISTOR 2SC3661
Q373 8-729-802-80 TRANSISTOR 2SC3661
Q374 8-729-802-80 TRANSISTOR 2SC3661
Q375 8-729-802-80 TRANSISTOR 2SC3661
Q376 8-729-802-80 TRANSISTOR 2SC3661
Q377 6-550-580-01 TRANSISTOR 2SA1235TP-1F
Q378 6-550-185-01 TRANSISTOR RT1P137P-TP-1
Q379 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q380 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q381 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q382 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q383 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q501 8-729-901-00 TRANSISTOR DTC124EK
Q504 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q505 8-729-901-00 TRANSISTOR DTC124EK
Q540 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q541 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q542 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q543 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q544 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q545 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q560 6-550-185-01 TRANSISTOR RT1P137P-TP-1
Q561 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q580 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q581 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q582 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q583 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q584 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q585 8-729-026-68 TRANSISTOR 2SD2525 (TP)
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-818-11 METAL CHIP 560 5% 1/10W
R104 1-216-821-11 METAL CHIP 1K 5% 1/10W
R105 1-216-841-11 METAL CHIP 47K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-813-11 METAL CHIP 220 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R131 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R132 1-216-857-11 METAL CHIP 1M 5% 1/10W
R133 1-216-845-11 METAL CHIP 100K 5% 1/10W
R140 1-216-833-11 METAL CHIP 10K 5% 1/10W
R150 1-216-809-11 METAL CHIP 100 5% 1/10W
R151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R152 1-216-833-11 METAL CHIP 10K 5% 1/10W
R153 1-216-818-11 METAL CHIP 560 5% 1/10W
R154 1-216-821-11 METAL CHIP 1K 5% 1/10W
R155 1-216-841-11 METAL CHIP 47K 5% 1/10W
R156 1-216-833-11 METAL CHIP 10K 5% 1/10W
R157 1-216-813-11 METAL CHIP 220 5% 1/10W
R166 1-216-809-11 METAL CHIP 100 5% 1/10W
R180 1-216-833-11 METAL CHIP 10K 5% 1/10W
R181 1-216-833-11 METAL CHIP 10K 5% 1/10W
R182 1-216-841-11 METAL CHIP 47K 5% 1/10W
R183 1-216-841-11 METAL CHIP 47K 5% 1/10W
R184 1-216-821-11 METAL CHIP 1K 5% 1/10W
R185 1-216-821-11 METAL CHIP 1K 5% 1/10W
R186 1-216-833-11 METAL CHIP 10K 5% 1/10W
R187 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-821-11 METAL CHIP 1K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-834-11 METAL CHIP 12K 5% 1/10W
R228 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R229 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R250 1-216-821-11 METAL CHIP 1K 5% 1/10W
R251 1-216-833-11 METAL CHIP 10K 5% 1/10W
R252 1-216-839-11 METAL CHIP 33K 5% 1/10W
R253 1-216-833-11 METAL CHIP 10K 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-833-11 METAL CHIP 10K 5% 1/10W
R256 1-216-839-11 METAL CHIP 33K 5% 1/10W
R257 1-216-821-11 METAL CHIP 1K 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R261 1-216-864-11 SHORT CHIP 0
R262 1-216-864-11 SHORT CHIP 0
R263 1-216-864-11 SHORT CHIP 0
R264 1-216-845-11 METAL CHIP 100K 5% 1/10W
R265 1-216-845-11 METAL CHIP 100K 5% 1/10W
R266 1-216-845-11 METAL CHIP 100K 5% 1/10W
R267 1-216-845-11 METAL CHIP 100K 5% 1/10W
R268 1-216-821-11 METAL CHIP 1K 5% 1/10W
R269 1-216-821-11 METAL CHIP 1K 5% 1/10W
R270 1-216-821-11 METAL CHIP 1K 5% 1/10W
R271 1-216-821-11 METAL CHIP 1K 5% 1/10W
R272 1-216-837-11 METAL CHIP 22K 5% 1/10W
R273 1-216-833-11 METAL CHIP 10K 5% 1/10W
R274 1-216-841-11 METAL CHIP 47K 5% 1/10W
R281 1-216-833-11 METAL CHIP 10K 5% 1/10W
R282 1-216-839-11 METAL CHIP 33K 5% 1/10W
R285 1-216-833-11 METAL CHIP 10K 5% 1/10W
R286 1-216-839-11 METAL CHIP 33K 5% 1/10W
R290 1-216-841-11 METAL CHIP 47K 5% 1/10W
R291 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R292 1-216-841-11 METAL CHIP 47K 5% 1/10W
R293 1-216-841-11 METAL CHIP 47K 5% 1/10W
R294 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R295 1-216-841-11 METAL CHIP 47K 5% 1/10W
R296 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R297 1-216-841-11 METAL CHIP 47K 5% 1/10W
R301 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R303 1-216-833-11 METAL CHIP 10K 5% 1/10W
R304 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R305 1-216-841-11 METAL CHIP 47K 5% 1/10W
R306 1-216-837-11 METAL CHIP 22K 5% 1/10W
R307 1-216-857-11 METAL CHIP 1M 5% 1/10W
R308 1-216-809-11 METAL CHIP 100 5% 1/10W
R309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R310 1-216-809-11 METAL CHIP 100 5% 1/10W
R311 1-216-864-11 SHORT CHIP 0
