Sony HCD-GPX6 - Disassembly; Disassembly Flow

HCD-GPX6/GPX7
8
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
SET
3-2. SIDE PLATE
(L)/(R)
(Page 9)
3-7. CD
MECHANISM
DECK BLOCK
(Page 11)
3-15. HOLDER
(BU215) ASSY
(Page 16)
3-16. LEVER
(BU LOCK)
(Page 16)
3-17. CLOSE
LEVER
(Page 17)
3-18. LEVER (DIR),
GEAR (IDL-B)
(Page 17)
3-9. MOTOR GEAR
ASSY (SLED)
(M102),
CD BOARD
(Page 12)
3-10. OPTICAL PICK-UP
(KSM-215DCP)
(Page 13)
3-8. BASE UNIT
(BU-F1BD81A)
(Page 12)
3-11. CHASSIS (TOP)
(Page 13)
3-14. DRIVER
BOARD
(Page 15)
3-12. LEVER
(LOADING-L/R)
(Page 14)
3-13. LEVER (DISC
SENSOR)/
(DISC STOP )
(Page 15)
3-19. GEAR
(IDL-C)
(Page 18)
3-4. TAPE MECHANISM DECK
(CMAL1Z234A)
(Page 10)
3-5. FRONT PANEL
SECTION
(Page 10)
3-6. MAIN BOARD
(Page 11)
3-3. TOP BLOCK
ASSY
(Page 9)
