Ref. No. Part No. Description Remarks
— 74 —
Ref. No. Part No. Description Remarks
CD BUTTON
< TERMINAL >
JK703 1-694-443-11 TERMINAL BOARD
< TRANSISTOR >
Q701 8-729-188-23 TRANSISTOR 2SD882-P
Q702 8-729-188-23 TRANSISTOR 2SD882-P
Q703 8-729-232-32 TRANSISTOR 2SA965
Q706 8-729-194-57 TRANSISTOR 2SC945-P
Q707 8-729-194-57 TRANSISTOR 2SC945-P
Q708 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q709 8-729-231-55 TRANSISTOR 2SC2878-AB
Q710 8-729-231-55 TRANSISTOR 2SC2878-AB
< RESISTOR >
R705 1-249-438-11 CARBON 56K 5% 1/4W
R706 1-249-438-11 CARBON 56K 5% 1/4W
R707 1-249-466-11 CARBON 56K 5% 1/4W
R708 1-249-466-11 CARBON 56K 5% 1/4W
R709 1-247-128-00 CARBON 750 1% 1/4W
R710 1-247-128-00 CARBON 750 1% 1/4W
R711 1-260-103-11 CARBON 2.2K 5% 1/2W
R712 1-260-103-11 CARBON 2.2K 5% 1/2W
R713 1-249-405-11 CARBON 100 5% 1/4W F
R714 1-249-405-11 CARBON 100 5% 1/4W F
R715 1-247-717-11 CARBON 2.2K 5% 1/4W F
R716 1-247-717-11 CARBON 2.2K 5% 1/4W F
R718 1-247-713-11 CARBON 1K 5% 1/4W F
R719 1-247-887-00 CARBON 220K 5% 1/4W
R720 1-247-887-00 CARBON 220K 5% 1/4W
R721 1-249-406-11 CARBON 120 5% 1/4W F
R722 1-249-406-11 CARBON 120 5% 1/4W F
R723 1-220-853-11 METAL 0.1 10% 2W
R724 1-220-853-11 METAL 0.1 10% 2W
R725 1-249-420-11 CARBON 1.8K 5% 1/4W F
R726 1-249-420-11 CARBON 1.8K 5% 1/4W F
R727 1-249-459-11 CARBON 12K 5% 1/4W
R728 1-249-459-11 CARBON 12K 5% 1/4W
R729 1-247-717-11 CARBON 2.2K 5% 1/4W F
R730 1-249-465-11 CARBON 47K 5% 1/4W
R731 1-247-887-00 CARBON 220K 5% 1/4W
R732 1-247-713-11 CARBON 1K 5% 1/4W F
R734 1-247-721-11 CARBON 4.7K 5% 1/4W F
R735 1-260-076-11 CARBON 10 5% 1/2W
R736 1-260-076-11 CARBON 10 5% 1/2W
R741 1-213-036-11 FUSIBLE 1 5% 1W F
R742 1-247-706-11 CARBON 330 5% 1/4W F
R743 1-247-714-11 CARBON 1.2K 5% 1/4W F
R744 1-247-708-11 CARBON 470 5% 1/4W F
R747 1-247-807-11 CARBON 100 5% 1/4W
R748 1-247-807-11 CARBON 100 5% 1/4W
R751 1-247-807-11 CARBON 100 5% 1/4W
R755 1-249-438-11 CARBON 56K 5% 1/4W
R756 1-249-438-11 CARBON 56K 5% 1/4W
R761 1-247-839-11 CARBON 2.2K 5% 1/4W
R762 1-247-839-11 CARBON 2.2K 5% 1/4W
R765 1-247-855-11 CARBON 10K 5% 1/4W
R767 1-247-839-11 CARBON 2.2K 5% 1/4W
< RELAY >
RL701 1-515-921-11 RELAY (12V)
************************************************************
* 1-670-443-11 CD BUTTON BOARD
****************
< LED >
LED602 8-719-046-80 DIODE SML19416W-TP4
LED603 8-719-046-80 DIODE SML19416W-TP4
LED604 8-719-046-80 DIODE SML19416W-TP4
< RESISTOR >
R680 1-247-841-11 CARBON 2.7K 5% 1/4W
R681 1-247-845-11 CARBON 3.9K 5% 1/4W F
R682 1-247-851-11 CARBON 6.8K 5% 1/4W
R683 1-247-859-11 CARBON 15K 5% 1/4W
R684 1-247-869-11 CARBON 39K 5% 1/4W
< SWITCH >
S624 1-762-875-11 SWITCH, KEYBOARD (DISK 1)
S625 1-762-875-11 SWITCH, KEYBOARD (DISK 2)
S626 1-762-875-11 SWITCH, KEYBOARD (DISK 3)
S627 1-762-875-11 SWITCH, KEYBOARD (DISK SKIP)
S628 1-762-875-11 SWITCH, KEYBOARD (OPEN/EJECT)
************************************************************
* A-4414-924-A CD DECODER BOARD, COMPLETE
****************************
< CAPACITOR >
C02 1-126-963-11 ELECT 4.7uF 20% 50V
C03 1-126-933-11 ELECT 100uF 20% 10V
C04 1-162-306-11 CERAMIC 0.01uF 20% 16V
C04A 1-164-159-11 CERAMIC 0.1uF 50V
C05 1-136-159-00 FILM 0.033uF 5% 50V
C06 1-162-306-11 CERAMIC 0.01uF 20% 16V
C07 1-136-159-00 FILM 0.033uF 5% 50V
C07A 1-162-199-31 CERAMIC 10PF 5% 50V
C08 1-161-494-00 CERAMIC 0.022uF 25V
C09 1-126-959-11 ELECT 0.47uF 20% 50V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-933-11 ELECT 100uF 20% 10V
C11A 1-164-159-11 CERAMIC 0.1uF 50V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-164-159-11 CERAMIC 0.1uF 50V
C14 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-136-159-00 FILM 0.033uF 5% 50V
C17 1-136-165-00 FILM 0.1uF 5% 50V
C18 1-164-159-11 CERAMIC 0.1uF 50V
C19 1-126-963-11 ELECT 4.7uF 20% 50V
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-136-157-00 FILM 0.022uF 5% 50V
C22 1-126-933-11 ELECT 100uF 20% 10V
C23 1-164-159-11 CERAMIC 0.1uF 50V
C24 1-126-965-11 ELECT 22uF 20% 50V
C25 1-126-960-11 ELECT 1uF 20% 50V
C26 1-161-494-00 CERAMIC 0.022uF 25V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C28 1-164-159-11 CERAMIC 0.1uF 50V
CD DECODERAMP
