– 101 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
C904 1-126-967-11 ELECT 47uF 20% 16V
C905 1-104-661-91 ELECT 330uF 20% 16V
C909 1-126-964-11 ELECT 10uF 20% 50V
C910 1-126-933-11 ELECT 100uF 20% 10V
C911 1-126-964-11 ELECT 10uF 20% 50V
C912 1-126-767-11 ELECT 1000uF 20% 16V
C913 1-126-943-11 ELECT 2200uF 20% 25V
C914 1-126-767-11 ELECT 1000uF 20% 16V
C915 1-126-967-11 ELECT 47uF 20% 16V
C916 1-164-159-11 CERAMIC 0.1uF 50V
C917 1-126-933-11 ELECT 100uF 20% 16V
C918 1-126-968-11 ELECT 100uF 20% 50V
C919 1-126-968-11 ELECT 100uF 20% 50V
C920 1-126-964-11 ELECT 10uF 20% 50V
C921 1-126-947-11 ELECT 47uF 20% 35V
C951 1-136-165-00 FILM 0.1uF 5% 50V
C952 1-126-943-11 ELECT 2200uF 20% 25V
C953 1-104-666-11 ELECT 220uF 20% 25V
C955 1-104-661-91 ELECT 330uF 20% 16V
< CONNECTOR >
CN101 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
* CN102 1-568-832-11 SOCKET, CONNECTOR 13P
(CND, E2, EA4, TH, MX, AUS)
CN102 1-568-834-11 SOCKET, CONNECTOR 15P
(EXCEPT CND, E2, EA4, TH, MX, AUS)
* CN103 1-568-946-11 PIN, CONNECTOR 8P
* CN104 1-568-947-11 PIN, CONNECTOR 9P
* CN105 1-568-862-11 SOCKET, CONNECTOR 19P
CN106 1-568-834-11 SOCKET, CONNECTOR 15P
* CN107 1-568-836-11 SOCKET, CONNECTOR 17P
CN110 1-564-506-11 PLUG, CONNECTOR 3P
(GRX7/GRX7J/RX77: CND)
* CN201 1-568-832-11 SOCKET, CONNECTOR 13P
* CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P
< DIODE >
D141 8-719-911-19 DIODE 1SS119
D401 8-719-911-19 DIODE 1SS119
D403 8-719-911-19 DIODE 1SS119 (GRX7/GRX7J/RX77: CND)
D404 8-719-911-19 DIODE 1SS119 (GRX7/GRX7J/RX77: CND)
D405 8-719-024-99 DIODE 11ES2-NTA2B
(GRX7/GRX7J/RX77: CND)
D406 8-719-024-99 DIODE 11ES2-NTA2B
(GRX7/GRX7J/RX77: CND)
D407 8-719-024-99 DIODE 11ES2-NTA2B
(GRX7/GRX7J/RX77: CND)
D501 8-719-024-99 DIODE 11ES2-NTA2B
D502 8-719-024-99 DIODE 11ES2-NTA2B
D503 8-719-911-19 DIODE 1SS119
D504 8-719-911-19 DIODE 1SS119
D505 8-719-911-19 DIODE 1SS119
D506 8-719-911-19 DIODE 1SS119
D507 8-719-024-99 DIODE 11ES2-NTA2B
D508 8-719-911-19 DIODE 1SS119
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-985-87 DIODE HZS6B1LTA
D906 8-719-911-19 DIODE 1SS119
D907 8-719-024-99 DIODE 11ES2-NTA2B
D908 8-719-024-99 DIODE 11ES2-NTA2B
D909 8-719-024-99 DIODE 11ES2-NTA2B
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-934-25 DIODE HZS33-1L
D912 8-719-921-48 DIODE MTZJ-T-72-5.6C
D913 8-719-911-19 DIODE 1SS119
D914 8-719-024-99 DIODE 11ES2-NTA2B
D915 8-719-986-17 DIODE HZS11B1LTA
< GROUND PLATE >
* EPT1 4-870-539-11 PLATE, GROUND
< IC >
IC101 8-759-495-24 IC M62442FP-TP (GRX7/GRX7J/RX77: CND)
IC101 8-759-495-86 IC M62442FP-A-TP (AEP, UK, G, EE, CIS)
IC102 8-759-634-51 IC M5218AP
IC191 8-759-634-50 IC M5218AL (GRX7/GRX7J/RX77: CND)
IC301 8-759-495-26 IC HA12215
IC381 8-749-923-04 IC TOTX178 (CD DIGITAL OUT, OPTICAL)
IC501 8-759-496-10 IC uPD780018AYGF-011-3BA
IC502 8-759-635-63 IC M51943BSL
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-231-53 IC TA7805S
IC903 8-759-231-58 IC TA7812S
< JACK >
J101 1-695-188-31 JACK, PIN 4P (MD/VIDEO (AUDIO), IN/OUT)
J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
(GRX7/GRX7J/RX77: CND)
< COIL >
L301 1-410-524-11 INDUCTOR 220uH
L302 1-410-524-11 INDUCTOR 220uH
L381 1-410-521-11 INDUCTOR 100uH
L392 1-410-521-11 INDUCTOR 100uH
L401 1-420-872-00 COIL, AIR-CORE (AEP, UK, G, AED, EE, CIS)
L451 1-420-872-00 COIL, AIR-CORE (AEP, UK, G, AED, EE, CIS)
L501 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q111 8-729-620-05 TRANSISTOR 2SC2603-EF
Q112 8-729-620-05 TRANSISTOR 2SC2603-EF
Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q161 8-729-620-05 TRANSISTOR 2SC2603-EF
Q162 8-729-620-05 TRANSISTOR 2SC2603-EF
Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623A-LK
(GRX7/GRX7J/RX77: CND)
Q331 8-729-118-00 TRANSISTOR 2SB1116-L
Q332 8-729-029-66 TRANSISTOR DTC114ESA
Q333 8-729-118-00 TRANSISTOR 2SB1116-L
Q334 8-729-029-66 TRANSISTOR DTC114ESA
Q335 8-729-029-66 TRANSISTOR DTC114ESA
Q336 8-729-116-57 TRANSISTOR 2SB1068-K
Q337 8-729-144-44 TRANSISTOR 2SD1513-K
