– 101 –
< RESISTOR >
R11 1-249-429-11 CARBON 10K 5% 1/4W
R12 1-249-441-11 CARBON 100K 5% 1/4W
R13 1-249-417-11 CARBON 1K 5% 1/4W F
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-247-807-31 CARBON 100 5% 1/4W
R17 1-247-807-31 CARBON 100 5% 1/4W
R18 1-247-807-31 CARBON 100 5% 1/4W
R19 1-249-427-11 CARBON 6.8K 5% 1/4W F
R20 1-249-429-11 CARBON 10K 5% 1/4W
R23 1-249-427-11 CARBON 6.8K 5% 1/4W F
< RELAY >
RY11 1-755-275-11 RELAY, AC POWER (RXD10AV:CND)
RY11 1-755-276-11 RELAY, POWER (RXD10AV:US,AEP,UK,G,CIS)
**************************************************************
* 1-672-369-11 TRANS BOARD
*************
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
(GRX90AV)
C972 1-126-960-11 ELECT 1uF 20% 50V
(GRX90AV)
C973 1-126-948-11 ELECT 100uF 20% 35V
(GRX90AV)
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P
* CN952 1-564-526-11 PLUG, CONNECTOR 11P (RXD10AV)
* CN952 1-564-527-11 PLUG, CONNECTOR 12P (GRX90AV)
CN971 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
(GRX90AV)
< DIODE >
D971 8-719-200-82 DIODE 11ES2 (GRX90AV)
D972 8-719-936-43 DIODE HZS27-3LTD (GRX90AV)
D973 8-719-109-63 DIODE RD3.0ESB2 (GRX90AV)
< FUSE >
! F951 1-532-464-31 FUSE (T2.5AL/250V) (AEP,UK,G,CIS)
! F951 1-532-505-31 FUSE (T5AL/250V) (E2,E3,EA,SP,AR,MX)
! F951 1-533-310-11 FUSE (6.3A/125V) (US,CND)
! F952 1-532-464-31 FUSE (T3.15AL/250V) (AUS)
! F952 1-532-465-31 FUSE (T3.15AL/250V) (E2,E3,EA,SP,AR,TH)
! F953 1-532-464-31 FUSE (T2.5AL/250V) (E2,E3,EA,SP,AR,AUS)
! F961 1-533-311-11 FUSE (8A/125V) (US,CND)
! F961 1-533-949-31 FUSE (T8AL/250V) (EXCEPT US,CND)
! F962 1-533-311-11 FUSE (8A/125V) (US,CND)
! F962 1-533-949-31 FUSE (T8AL/250V) (EXCEPT US,CND)
< FUSE HOLDER >
FH901 1-533-217-31 HOLDER, FUSE (EXCEPT AUS,TH)
FH902 1-533-217-31 HOLDER, FUSE (E2,E3,EA,SP,AR,TH)
FH903 1-533-217-31 HOLDER, FUSE (E2,E3,EA,SP,AR,AUS)
FH911 1-533-217-31 HOLDER, FUSE
FH912 1-533-217-31 HOLDER, FUSE
FH951 1-533-217-31 HOLDER, FUSE (EXCEPT AUS,TH)
FH952 1-533-217-31 HOLDER, FUSE (E2,E3,EA,SP,AR,TH)
FH953 1-533-217-31 HOLDER, FUSE (E2,E3,EA,SP,AR,AUS)
FH961 1-533-217-31 HOLDER, FUSE
FH962 1-533-217-31 HOLDER, FUSE
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)(GRX90AV)
< RESISTOR >
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R961 1-202-725-00 SOLID 3.3M 10% 1/2W
(RXD10AV:US,CND)
! R971 1-216-479-11 METAL OXIDE 560 5% 3W F
(GRX90AV)
R972 1-249-429-11 CARBON 10K 5% 1/4W
(GRX90AV)
R973 1-249-429-11 CARBON 10K 5% 1/4W
(GRX90AV)
R974 1-247-807-31 CARBON 100 5% 1/4W
(GRX90AV)
R975 1-247-807-31 CARBON 100 5% 1/4W
(GRX90AV)
< SWITCH >
! S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(GRX90AV)
! S951 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(GRX90AV)
**************************************************************
MISCELLANEOUS
*************
5 1-233-545-11 TUNER UNIT (FM/AM)(AR,MX,AUS,TH)
5 1-233-546-11 TUNER UNIT (FM/MW/SW)(E3,EA,SP)
5 1-693-443-11 TUNER UNIT (FM/AM)(AEP,UK,G,CIS)
5 1-693-445-11 TUNER UNIT (FM/AM)(US,CND)
5 1-693-453-11 TUNER UNIT (FM/AM)(E2)
54 1-783-570-11 WIRE (FLAT TYPE)(19 CORE)
55 1-769-976-11 WIRE (FLAT TYPE)(13 CORE)(140 mm)
55 1-773-008-11 WIRE (FLAT TYPE)(15 CORE)
56 1-773-049-11 WIRE (FLAT TYPE)(17 CORE)
58 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
58 1-569-008-21 ADAPTOR, CONVERSION 2P (EA,SP)
58 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
! 59 1-575-651-11 CORD, POWER (AEP,UK,G,CIS,EA,SP)
! 59 1-575-653-11 CORD, POWER (E2,E3,MX,TH)
! 59 1-690-608-11 CORD, POWER (AUS)
! 59 1-690-609-21 CORD, POWER (CND)
! 59 1-783-531-21 CORD, POWER (US)
! 59 1-783-941-21 CORD, POWER (AR)
62 1-773-023-11 WIRE (FLAT TYPE)(15 CORE)(310 mm)
116 1-773-189-11 WIRE (FLAT TYPE)(23 CORE)
121 1-674-232-11 PUSH CATCH STOP BOARD
257 1-452-925-21 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
TRANS
SUB TRANS
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
To Next Page
