HCD-HDX275/HDX277WC/HDX279W/HDX475/HDX576WF/HDX675
15
3-6. BACK PANEL BLOCK (HDX277WC/HDX279W/HDX576WF)
RG
screw
(B3
×
6)
screw (BV3)
R
terminal
RB
screw (BV3)
RT
three screws
(BV3)
RI
back panel block
RE
five screws
(BV3)
wire (flat type) (17 core)
(CN4302)
wire (flat type) (17 core)
(CN651)
wire (flat type) (7 core)
(CN653)
wire (flat type) (9 core)
(CN606)
wire (flat type) (5 core)
(CN702)
connector
(CN908)
power cord connector
(CN901)
fan motor connector
(CN3000)
RH
four claws
power cord
RH
screw
(BVTP3
×
12)
RG
two screws
(BV3)
RB
three screws
(BV3)
RL
seven screws
(BV3)
two connectors
(CN904, CN906)
R
two connectors
(CN1201, CN3001)
connector
(CN650)
SERIPARA board
wire (flat type) (21 core)
(CN651)
wire (flat type) (24 core)
(CN1101)
RM
MAIN board
wire (flat type) (21 core)
(CN501)
RT
plate insulated (POW)
RE
plate shield (POW-DCR)
RK
two radiation sheets
two screws
(BV3)
SPEAKER board
RI
heatsink (AMP)
connector
(CN114: HDX275/HDX277WC/
HDX475/HDX675,
CN115: HDX279W/HDX576WF)
3-7. SPEAKER BOARD, SERIPARA BOARD AND MAIN BOARD
