9
HCD-RV20/RV50/RV60
2-3. CD MECHANISM BLOCK
2
CN701
1
CN301
8
CN312
(flat type)
6
7
3
three
screws
(+BVTP 3
×
10)
9
CD mechanism block
5
screw
(+BVTP 3
×
10
)
4
screw
(+BVTP 3
×
10)
MAIN board
MAIN board
