HCD-RV2/RV5/RV6
4-1. CIRCUIT BOARDS LOCATION
SECTION 4
DIAGRAMS
MOTOR board
SENSOR (CD) board
DRIVER board
VIDEO board
VIDEO OUT board
TRANS board
SENSOR board
BD board
SURROUND board
SUB TRANS board
MAIN board
POWER AMP board
PANEL board
REMOTE board
KEY board
MIC board
(HCD-RV5/RV6)
(HCD-RV6
)
