HCD-RV2/RV5/RV6
4-29. PRINTED WIRING BOARD — SUB TRANS SECTION (HCD-RV5) — • Refer to page 16 for Circuit Boards Location.
1
A
B
C
D
E
F
G
23456
*
JW1
D901
R902
B
43
2
1
1
4
2
1
6
5
2
3
4
1
2
E
3
3
1
CN903
IC901
C903
D904
*
JW4
*
CN2(2pin): TH MODEL
(4pin): E3,EA,JE,MY,SP MODEL
JW1: THMODEL
JW3: TH MODEL
JW4: E3,EA,JE,MY,SP MODEL
T901
1-685-102-
11
(11)
*
CN2
C901
CN901
D905
D902
D903
C902
Q901
RY901
SUB TRANS BOARD
Q
TRANS BOARD
CN913
R
TRANS BOARD
CN3
AC
IN
*
JW3
(Page 45)
(Page 45)
Ref. No. Location
D901 B-2
D902 D-5
D903 D-5
D904 D-4
D905 D-5
IC901 B-5
Q901 B-4
• Semiconductor
Location
