73
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C774 1-126-935-11 ELECT 470uF 20% 10V
C775 1-162-306-11 CERAMIC 0.01uF 30% 16V
C776 1-162-306-11 CERAMIC 0.01uF 30% 16V
C777 1-164-159-21 CERAMIC 0.1uF 50V
C780 1-164-159-21 CERAMIC 0.1uF 50V
C781 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CN701 1-816-422-11 PIN, CONNECTOR 3P
CN711 1-793-767-11 CONNECTOR, BOARD TO BOARD 30P
CN712 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< DIODE >
D712 8-719-109-85 DIODE RD5.1ES-B2
D713 8-719-991-33 DIODE 1SS133T-77
D714 8-719-991-33 DIODE 1SS133T-77
D715 8-719-991-33 DIODE 1SS133T-77
D716 8-719-991-33 DIODE 1SS133T-77
< COIL >
FB701 1-412-473-21 INDUCTOR (SMALL TYPE)
< FLUORESCENT INDICATOR >
FLD701 1-518-793-12 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 6-801-360-01 IC uPD780232GC-059-8BT
IC702 8-759-710-97 IC NJM4565M-D
IC703 8-759-496-40 IC M65850FP
IC704 8-759-295-90 IC NJM2244M-TE2
< JACK >
JK701 1-691-293-21 JACK (PHONES)
JK704 1-815-684-11 JACK, PIN 3P (GAME INPUT
VIDEO/AUDIO,L/R)
< DIODE >
LED701 8-719-058-04 LED SEL5223S-TP15 (?/1)
LED702 8-719-057-97 LED SEL5923A-TP15 (GAME)
LED703 8-719-057-97 LED SEL5923A-TP15 (TAPE A/B)
LED704 8-719-057-97 LED SEL5923A-TP15 (CD)
LED705 8-719-057-97 LED SEL5923A-TP15 (TUNER/BAND)
LED706 8-719-057-97 LED SEL5923A-TP15 (MD VIDEO)
< TRANSISTOR >
Q701 8-729-900-63 TRANSISTOR DTA124ES
Q702 8-729-116-02 TRANSISTOR BA1A4M-TP
Q703 8-729-116-02 TRANSISTOR BA1A4M-TP
Q704 8-729-116-02 TRANSISTOR BA1A4M-TP
Q705 8-729-116-02 TRANSISTOR BA1A4M-TP
Q706 8-729-116-02 TRANSISTOR BA1A4M-TP
Q707 8-729-116-02 TRANSISTOR BA1A4M-TP
Q708 8-729-116-02 TRANSISTOR BA1A4M-TP
Q711 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R701 1-249-413-11 CARBON 470 5% 1/4W
R702 1-249-415-11 CARBON 680 5% 1/4W
R703 1-249-417-11 CARBON 1K 5% 1/4W
R704 1-249-419-11 CARBON 1.5K 5% 1/4W
R705 1-249-419-11 CARBON 1.5K 5% 1/4W
R706 1-249-421-11 CARBON 2.2K 5% 1/4W
R707 1-247-843-11 CARBON 3.3K 5% 1/4W
R708 1-249-413-11 CARBON 470 5% 1/4W
R709 1-249-415-11 CARBON 680 5% 1/4W
R710 1-249-417-11 CARBON 1K 5% 1/4W
R711 1-249-419-11 CARBON 1.5K 5% 1/4W
R712 1-249-419-11 CARBON 1.5K 5% 1/4W
R713 1-249-421-11 CARBON 2.2K 5% 1/4W
R714 1-247-843-11 CARBON 3.3K 5% 1/4W
R715 1-249-425-11 CARBON 4.7K 5% 1/4W
R739 1-249-417-11 CARBON 1K 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
R741 1-249-421-11 CARBON 2.2K 5% 1/4W
R742 1-249-421-11 CARBON 2.2K 5% 1/4W
R743 1-249-437-11 CARBON 47K 5% 1/4W
R744 1-249-437-11 CARBON 47K 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-249-413-11 CARBON 470 5% 1/4W
R747 1-249-431-11 CARBON 15K 5% 1/4W
R748 1-249-431-11 CARBON 15K 5% 1/4W
R749 1-249-431-11 CARBON 15K 5% 1/4W
R750 1-249-429-11 CARBON 10K 5% 1/4W
R751 1-249-437-11 CARBON 47K 5% 1/4W
R752 1-249-429-11 CARBON 10K 5% 1/4W
R753 1-249-429-11 CARBON 10K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
R758 1-247-807-31 CARBON 100 5% 1/4W
R759 1-249-429-11 CARBON 10K 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-249-429-11 CARBON 10K 5% 1/4W
R762 1-247-807-31 CARBON 100 5% 1/4W
R763 1-249-429-11 CARBON 10K 5% 1/4W
R764 1-249-429-11 CARBON 10K 5% 1/4W
R765 1-247-903-00 CARBON 1M 5% 1/4W
R767 1-249-417-11 CARBON 1K 5% 1/4W
R768 1-247-807-31 CARBON 100 5% 1/4W
R769 1-249-401-11 CARBON 47 5% 1/4W
R770 1-249-417-11 CARBON 1K 5% 1/4W
R771 1-249-430-11 CARBON 12K 5% 1/4W
R772 1-249-429-11 CARBON 10K 5% 1/4W
R773 1-249-433-11 CARBON 22K 5% 1/4W
R774 1-249-433-11 CARBON 22K 5% 1/4W
R775 1-249-433-11 CARBON 22K 5% 1/4W
R776 1-249-410-11 CARBON 270 5% 1/4W
R777 1-247-881-00 CARBON 120K 5% 1/4W
R778 1-249-437-11 CARBON 47K 5% 1/4W
R779 1-249-433-11 CARBON 22K 5% 1/4W
R780 1-249-433-11 CARBON 22K 5% 1/4W
R781 1-249-433-11 CARBON 22K 5% 1/4W
R782 1-249-431-11 CARBON 15K 5% 1/4W
R783 1-249-417-11 CARBON 1K 5% 1/4W
R784 1-249-441-11 CARBON 100K 5% 1/4W
R785 1-249-429-11 CARBON 10K 5% 1/4W
R786 1-249-417-11 CARBON 1K 5% 1/4W
PANEL
