HCD-RV2/RV5/RV6
< TRANSFORMER >
0T901 1-435-828-11 TRANSFORMER, POWER
*************************************************************
1-685-110-11 SUB TRANS BOARD (RV6)
****************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
* CN2 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P (TH)
CN2 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(E3,EA,MY,SP)
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CN903 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC901 6-701-760-01 IC uPC3504AHF
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R902 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-435-828-11 TRANSFORMER, POWER
*************************************************************
1-685-089-11 SURROUND BOARD (RV6)
****************
< TERMINAL BOARD >
JK303 1-694-632-12 TERMINAL BOARD (4P) (SURROUND SPEAKER)
(RV6)
*************************************************************
1-685-090-11 TRANS BOARD
************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C911 1-128-553-11 ELECT 220uF 20% 63V
C912 1-126-964-11 ELECT 10uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN915 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D911 8-719-200-82 DIODE 11ES2
D912 8-719-982-15 DIODE MTZJ-27B (RV2)
D912 8-719-982-20 DIODE MTZJ-30B (RV5/RV6)
D913 8-719-109-89 DIODE RD5.6ES-B2
< TRANSISTOR >
Q911 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
R905 1-249-417-11 CARBON 1K 5% 1/4W
0R911 1-217-637-00 FUSIBLE 1 5% 1/4W F
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-249-417-11 CARBON 1K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
0R920 1-219-122-00 FUSIBLE 0.33 5% 1/4W F
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(E3,EA,JE,MY,SP)
*************************************************************
A-4676-362-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C104 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C105 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C106 1-164-670-11 CERAMIC CHIP 0.0012uF 5% 16V
C114 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C116 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C154 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C155 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C156 1-164-670-11 CERAMIC CHIP 0.0012uF 5% 16V
C201 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C203 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C212 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C213 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C214 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C221 1-124-779-00 ELECT CHIP 10uF 20% 16V
C222 1-124-779-00 ELECT CHIP 10uF 20% 16V
TRANSSURROUND VIDEOSUB TRANS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
