76
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R784 1-249-441-11 CARBON 100K 5% 1/4W
R785 1-249-429-11 CARBON 10K 5% 1/4W
R786 1-249-417-11 CARBON 1K 5% 1/4W
R787 1-249-437-11 CARBON 47K 5% 1/4W
R788 1-247-807-31 CARBON 100 5% 1/4W
R789 1-249-429-11 CARBON 10K 5% 1/4W
R790 1-247-885-00 CARBON 180K 5% 1/4W
R791 1-247-807-31 CARBON 100 5% 1/4W
R792 1-249-441-11 CARBON 100K 5% 1/4W
R795 1-249-431-11 CARBON 15K 5% 1/4W
R796 1-249-401-11 CARBON 47 5% 1/4W
R799 1-249-401-11 CARBON 47 5% 1/4W
R800 1-249-429-11 CARBON 10K 5% 1/4W
R801 1-247-804-11 CARBON 75 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-249-437-11 CARBON 47K 5% 1/4W
< VIBRATOR >
RES701 1-579-233-11 VIBRATOR, CERAMIC (5MHz)
< SWITCH >
S701 1-762-875-21 SWITCH, KEYBOARD (CD)
S702 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S703 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S704 1-762-875-21 SWITCH, KEYBOARD (MD (VIDEO))
S705 1-762-875-21 SWITCH, KEYBOARD (GAME)
S706 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON)
S707 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S708 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S709 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S710 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S711 1-762-875-21 SWITCH, KEYBOARD (OPEN/CLOSE Z)
S712 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE)
S713 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY/
PLAY MODE)
S714 1-762-875-21 SWITCH, KEYBOARD (FM MODE/REPEAT)
S715 1-762-875-21 SWITCH, KEYBOARD (DIRECTION/EDIT)
S716 1-762-875-21 SWITCH, KEYBOARD (?/1)
S742 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< ROTARY ENCODER >
VR701 1-418-725-41 ENCODER, ROTARY (VOLUME)
< VARIABLE RESISTOR >
VR702 1-225-739-11 RES, VAR, CARBON 50K (ECHO LEVEL)
VR703 1-225-739-11 RES, VAR, CARBON 50K (MIC LEVEL)
*************************************************************
A-4676-989-A POWER AMP BOARD, COMPLETE (RV2)
***************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-286-21 CERAMIC 220PF 10% 50V
C504 1-128-551-11 ELECT 22uF 20% 25V
C507 1-130-493-00 MYLAR 0.068uF 5% 50V
C508 1-130-493-00 MYLAR 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30% 16V
C541 1-130-777-00 MYLAR 0.1uF 10% 100V
C542 1-137-841-11 ELECT 2200uF 20% 71V
C543 1-164-159-21 CERAMIC 0.1uF 50V
C544 1-126-942-61 ELECT 1000uF 20% 25V
C546 1-128-549-11 ELECT 3300uF 20% 35V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-21 CERAMIC 220PF 10% 50V
C554 1-128-551-11 ELECT 22uF 20% 25V
C557 1-130-493-00 MYLAR 0.068uF 5% 50V
C558 1-130-493-00 MYLAR 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C591 1-130-777-00 MYLAR 0.1uF 10% 100V
C592 1-137-841-11 ELECT 2200uF 20% 71V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D541 8-719-510-68 DIODE D5SBA20-4101
D542 8-719-200-82 DIODE 11ES2
D543 8-719-200-82 DIODE 11ES2
D551 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-93 IC STK402-070S
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q503 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q504 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q551 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q581 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q582 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q583 8-729-116-01 TRANSISTOR BA1F4M-TP
Q584 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-416-11 CARBON 820 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
R508 1-217-156-00 METAL 0.22X2 10% 5W
POWER AMPPANEL
