77
HCD-RV2/RV5/RV6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R509 1-260-076-11 CARBON 10 5% 1/2W
R510 1-217-156-00 METAL 0.22X2 10% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W F
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-425-11 CARBON 4.7K 5% 1/4W
R518 1-249-429-11 CARBON 10K 5% 1/4W
R520 1-249-441-11 CARBON 100K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-409-11 CARBON 220 5% 1/4W
R524 1-247-897-11 CARBON 560K 5% 1/4W
R525 1-249-437-11 CARBON 47K 5% 1/4W
R541 1-260-344-51 CARBON 22K 5% 1/2W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-416-11 CARBON 820 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
R558 1-217-156-00 METAL 0.22X2 10% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
R560 1-217-156-00 METAL 0.22X2 10% 5W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W F
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-260-344-51 CARBON 22K 5% 1/2W
0R592 1-219-591-11 FUSIBLE 0.1 5% 1/2W F
0R593 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
*************************************************************
A-4729-266-A POWER AMP BOARD, COMPLETE (RV5)
***************************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-162-294-31 CERAMIC 0.001uF 10% 50V
C503 1-162-286-21 CERAMIC 220PF 10% 50V
C504 1-128-551-11 ELECT 22uF 20% 25V
C507 1-130-493-00 MYLAR 0.068uF 5% 50V
C508 1-130-493-00 MYLAR 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30% 16V
C541 1-130-777-00 MYLAR 0.1uF 10% 100V
C542 1-137-840-11 ELECT 2200uF 20% 63V
C543 1-164-159-21 CERAMIC 0.1uF 50V
C544 1-126-942-61 ELECT 1000uF 20% 25V
C546 1-128-549-11 ELECT 3300uF 20% 35V
C551 1-126-964-11 ELECT 10uF 20% 50V
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-21 CERAMIC 220PF 10% 50V
C554 1-128-551-11 ELECT 22uF 20% 25V
C557 1-130-493-00 MYLAR 0.068uF 5% 50V
C558 1-130-493-00 MYLAR 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C591 1-130-777-00 MYLAR 0.1uF 10% 100V
C592 1-137-840-11 ELECT 2200uF 20% 63V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
* CN504 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D541 8-719-510-68 DIODE D5SBA20-4101
D542 8-719-200-82 DIODE 11ES2
D543 8-719-200-82 DIODE 11ES2
D551 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-016-96 IC STK402-120S
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q582 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q583 8-729-116-01 TRANSISTOR BA1F4M-TP
Q584 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-416-11 CARBON 820 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
R508 1-217-156-00 METAL 0.22X2 10% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
R510 1-217-156-00 METAL 0.22X2 10% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W F
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-425-11 CARBON 4.7K 5% 1/4W
R518 1-249-429-11 CARBON 10K 5% 1/4W
R520 1-249-441-11 CARBON 100K 5% 1/4W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-409-11 CARBON 220 5% 1/4W
R524 1-247-897-11 CARBON 560K 5% 1/4W
R525 1-249-437-11 CARBON 47K 5% 1/4W
POWER AMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
