Page #74 background imageLoading...
Page #74 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
74
HCD-RV7/RV8
C285 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-130-483-00 MYLAR 0.01uF 5% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-960-11 ELECT 1uF 20% 50V
C306 1-126-961-11 ELECT 2.2uF 20% 50V
C307 1-126-964-11 ELECT 10uF 20% 50V
C308 1-126-935-11 ELECT 470uF 20% 16V
C309 1-126-947-11 ELECT 47uF 20% 16V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-964-11 ELECT 10uF 20% 50V
C314 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-115-156-11 CERAMIC CHIP 1uF 10V
C321 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C326 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C331 1-130-483-00 MYLAR 0.01uF 5% 50V
C332 1-137-427-11 MYLAR 120PF 5% 50V
C333 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C334 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C335 1-137-150-11 MYLAR 0.01uF 5% 100V
C336 1-126-961-11 ELECT 2.2uF 20% 50V
C337 1-130-485-00 MYLAR 0.015uF 5% 50V
C338 1-130-481-00 MYLAR 0.0068uF 5% 50V
C339 1-130-481-00 MYLAR 0.0068uF 5% 50V
C340 1-130-486-00 MYLAR 0.018uF 10% 50V
C341 1-126-964-11 ELECT 10uF 20% 50V
C342 1-126-947-11 ELECT 47uF 20% 16V
C351 1-130-483-00 MYLAR 0.01uF 5% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-960-11 ELECT 1uF 20% 50V
C356 1-126-961-11 ELECT 2.2uF 20% 50V
C359 1-126-947-11 ELECT 47uF 20% 16V
C361 1-126-964-11 ELECT 10uF 20% 50V
C362 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C363 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C364 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C365 1-115-156-11 CERAMIC CHIP 1uF 10V
C371 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C376 1-164-392-11 CERAMIC CHIP 390PF 10% 50V
C381 1-130-483-00 MYLAR 0.01uF 5% 50V
C382 1-137-427-11 MYLAR 120PF 5% 50V
C383 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C384 1-162-946-11 CERAMIC CHIP 27PF 5% 50V
C385 1-126-964-11 ELECT 10uF 20% 50V
C390 1-126-935-11 ELECT 470uF 20% 10V
C391 1-126-933-11 ELECT 100uF 20% 16V
C395 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C396 1-126-965-11 ELECT 22uF 20% 50V
C397 1-126-964-11 ELECT 10uF 20% 50V
C398 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C399 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C432 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C433 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C434 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C498 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C504 1-109-889-11 ELECT 1uF 20% 50V
C510 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C511 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C512 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C516 1-104-656-11 ELECT 2200uF 20% 6.3V
C530 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C546 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C562 1-104-665-11 ELECT 100uF 20% 10V
C564 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C596 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C598 1-126-964-11 ELECT 10uF 20% 50V
C601 1-126-964-11 ELECT 10uF 20% 50V
C602 1-136-165-00 FILM 0.1uF 5% 50V
C603 1-136-165-00 FILM 0.1uF 5% 50V
C701 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C702 1-126-961-11 ELECT 2.2uF 20% 50V
C703 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C704 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C705 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C751 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C752 1-126-961-11 ELECT 2.2uF 20% 50V
C781 1-126-933-11 ELECT 100uF 20% 16V
C782 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C783 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C784 1-126-964-11 ELECT 10uF 20% 50V
C785 1-126-916-11 ELECT 1000uF 20% 6.3V
C786 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C788 1-126-964-11 ELECT 10uF 20% 50V
C813 1-107-721-11 ELECT 4.7uF 20% 100V
C861 1-107-717-11 ELECT 47uF 20% 50V
C863 1-107-721-11 ELECT 4.7uF 20% 100V
C892 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-136-165-00 FILM 0.1uF 5% 50V
(HCD-RV8)
C902 1-136-165-00 FILM 0.1uF 5% 50V
(HCD-RV8)
C903 1-126-382-11 ELECT 100uF 20% 6.3V
(HCD-RV8)
C904 1-162-945-11 CERAMIC CHIP 22PF 5% 50V
(HCD-RV8)
C905 1-115-872-11 ELECT 2.2uF 20% 50V
(HCD-RV8)
C906 1-115-871-11 ELECT 1uF 20% 50V
(HCD-RV8)
C907 1-115-872-11 ELECT 2.2uF 20% 50V
(HCD-RV8)
C908 1-126-514-11 ELECT 22uF 20% 16V
(HCD-RV8)
C909 1-126-942-61 ELECT 1000uF 20% 25V
C910 1-126-768-11 ELECT 2200uF 20% 16V
C911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C912 1-126-917-11 ELECT 3300uF 20% 6.3V
C913 1-136-165-00 FILM 0.1uF 5% 50V
(HCD-RV8)
C914 1-136-165-00 FILM 0.1uF 5% 50V
C915 1-136-165-00 FILM 0.1uF 5% 50V
C916 1-136-165-00 FILM 0.1uF 5% 50V
C917 1-136-165-00 FILM 0.1uF 5% 50V
