Sony HCD-RX80 - Waveforms

– 42 –
• Waveforms
1 IC101 #£ pin (RF_O)
0.1
V
5.6 V
135.5
µ
sec
0.2
V
10 V
59.8 nsec
7
V
230 nsec
5.6 V
135.5 µ sec
1.3 ± 0.3 Vp-p
2 IC101 2 pin (FEI)
3 IC101 $¶ pin (TEI)
4 IC103 @¶ pin (MDP)
2.4
V
7.8 µ sec
5 IC103 ^º pin (XPCK)
6 IC103 ^™ pin (RFCK)
7 IC103 &¢ pin (WFCK)
8 IC103 *ª pin (XTAI)
