Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4392-351-A HP/MIC BOARD, COMPLETE
***********************
< CAPACITOR >
C750 1-162-294-31 CERAMIC 0.001uF 10% 50V
C751 1-162-294-31 CERAMIC 0.001uF 10% 50V
C752 1-164-159-11 CERAMIC 0.1uF 50V
C753 1-164-159-11 CERAMIC 0.1uF 50V
C753 1-164-159-21 CERAMIC 0.1uF 50V
C754 1-162-306-11 CERAMIC 0.01uF 20% 16V
C755 1-126-961-11 ELECT 2.2uF 20% 50V
C756 1-162-294-31 CERAMIC 0.001uF 10% 50V
C757 1-162-215-31 CERAMIC 47PF 5% 50V
C758 1-126-964-11 ELECT 10uF 20% 50V
C759 1-126-959-11 ELECT 0.47uF 20% 50V
C760 1-162-215-31 CERAMIC 47PF 5% 50V
C761 1-162-282-31 CERAMIC 100PF 10% 50V
C762 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-126-964-11 ELECT 10uF 20% 50V
C782 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
* CN750 1-568-828-11 SOCKET, CONNECTOR 9P
< IC >
IC750 8-759-634-51 IC M5218AP
< JACK >
J750 1-569-112-21 JACK, LARGE TYPE (PHONES)
J751 1-569-112-21 JACK, LARGE TYPE (MIX MIC)
< RESISTOR >
R750 1-249-429-11 CARBON 10K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-441-11 CARBON 100K 5% 1/4W
R753 1-249-417-11 CARBON 1K 5% 1/4W
R754 1-249-433-11 CARBON 22K 5% 1/4W
R755 1-249-429-11 CARBON 10K 5% 1/4W
R756 1-247-885-00 CARBON 180K 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV750 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
******************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1003 1-571-281-21 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-572-248-11 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* A-4392-693-A MAIN BOARD, COMPLETE (AEP, G, UK, AED)
* A-4392-694-A MAIN BOARD, COMPLETE (EE, CIS)
**********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C109 1-164-159-11 CERAMIC 0.1uF 50V
C121 1-162-286-31 CERAMIC 220PF 10% 50V
C122 1-162-286-31 CERAMIC 220PF 10% 50V
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
C132 1-136-495-11 FILM 0.068uF 5% 50V
C133 1-162-294-31 CERAMIC 0.001uF 10% 50V
C134 1-164-159-11 CERAMIC 0.1uF 50V
C171 1-162-286-31 CERAMIC 220PF 10% 50V
C172 1-162-286-31 CERAMIC 220PF 10% 50V
C173 1-162-306-11 CERAMIC 0.01uF 20% 16V
C181 1-136-495-11 FILM 0.068uF 5% 50V
C182 1-136-495-11 FILM 0.068uF 5% 50V
C183 1-162-294-31 CERAMIC 0.001uF 10% 50V
C184 1-164-159-11 CERAMIC 0.1uF 50V
C201 1-136-169-00 FILM 0.22uF 5% 50V
HP/MIC LEAF SWITCH MAIN
