9
HCD-VX555/VX555J
2-7. LEAF SW BOARD, HEAD (A) BOARD AND HEAD (B) BOARD
2-6. MAIN BOARD AND POWER BOARD
4 Three screws (+BVTP 3 × 10)
6 Two screws (+BVTP 3 × 8)
7 Heat sink
3 Two screws (+BVTP 3 × 16)
1 Two screws (+BVTP 3 × 10
)
2 MAIN board
5 POWER board
MAIN board
5 Screw (+PTT 2 × 4)
3 Screw (+PTT 2 × 4)
2 LEAF SW board
1 Five claws
4 HEAD (A) board
6 HEAD (B) board
Remove the four solderings.
