11
Base unit
3
2 Four screws (+PTPWH 2.6)
4 Two insulators
5 Two insulators
1 Flat type wire (CN101)
qf Video boar
d
qd Two screws (+BVTP 2.6 × 8)
4 Three screws (+BVTP 2.6 × 8)
9 Screw (+PTPWH 2.6 × 8)
q; Tray
1 Screw (+BVTP 2.6 × 8)
qa Screw (+BVTP 2.6 × 8)
7 Flat type wire (CN721)
6 Motor board
qs Sensor board
8 Connector(CN722)
2 Driver board
3 Connector (CN701)
5 Remove the two solderings of motor.
3-9. BASE UNIT
3-10. DRIVER BOARD, MOTOR BOARD SENSOR BOARD AND VIDEO BOARD
