HCD-IS10
13
3-7. IO BOARD
3-6. MAIN BOARD
qd
four screws
(BVTP3
×
8)
5
wire (flat type)
(CN102) (9 core: except AEP, UK, Russian models)/
(CN101) (11 core: AEP, UK, Russian models)
6
wire (flat type) (21 core)
(CN103)
1
screw
(BVTP3
×
8)
2
insulating sheet
(motor)
US, Canadian
8
connector (CN107)
9
connector (CN111)
3
two screws
(BVTP3
×
8)
4
shield plate (side-L)
7
wire (flat type) (19 core)
(CN105)
0
wire (flat type) (9 core)
(CN110)
qs
wire (flat type) (13 core)
(CN106)
qf
MAIN board
qa
wire (flat type) (11 core)
(CN109)
– back view –
1
wire (flat type) (21 core)
(CN103)
3
two screws
(BVTP3
×
8)
6
five screws
(BVTP3
×
8)
4
screw
(BVTT3
×
8)
5
2
screw
(BVTP3
×
8)
7
back panel (HCD)
8
IO board
– back view –
